6-2
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
HK : Hong Kong model
AUS : Australian model
JE : Tourist model
• Due to standardization, replacements in the parts
list may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
Note:
When indicating parts by reference
number, please include the board
name.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
CD-227
FC-69
A-7073-962-A CD-227 BOARD, COMPLETE
*********************
(Ref. No. 2,000 Series)
(IC401 is not including to the mounted board)
< CAPACITOR >
C401 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C403 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C404 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
C405 1-135-210-11 TANTALUM CHIP 4.7uF 20% 10V
< CONNECTOR >
CN401 1-766-346-21 CONNECTOR, FFC/FPC 16P
< IC >
IC401 A-7030-901-A CCD BLOCK ASSY (CCD IMAGER)
< COIL >
L401 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q401 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R401 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R402 1-216-809-11 METAL CHIP 100 5% 1/16W
R403 1-216-809-11 METAL CHIP 100 5% 1/16W
**************************************************************
A-709-435-0A FC-69 BOARD, COMPLETE (SERVICE)
******************************
(Ref. No. 1,000 Series)
< CAPACITOR >
C103 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C104 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C107 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-135-214-21 TANTAL. CHIP 4.7uF 20% 20V
C109 1-115-156-11 CERAMIC CHIP 1uF 10V
C110 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C111 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C112 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C113 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C114 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C116 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C117 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C119 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C120 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C121 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C122 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C124 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C125 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C126 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C127 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C129 1-164-346-11 CERAMIC CHIP 1uF 16V
C130 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C131 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C132 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C133 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C134 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C136 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C302 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C303 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C401 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C402 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C403 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C404 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C405 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C406 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C407 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C408 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C409 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C410 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C411 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C412 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C413 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C415 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C417 1-164-346-11 CERAMIC CHIP 1uF 16V
C418 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C419 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C422 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C501 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C502 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C503 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C504 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C602 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C603 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C604 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C605 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C606 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
