4-1. PRINTED WIRING BOARD AND SCHEMATIC DIAGRAMS
SECTION 4
PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS
PK-46 BOARD (SIDE A)
BH701 E-1
BZ701 E-7
C704 D-1
C705 D-1
C851 D-7
(S) C852 B-7
C854 C-7
C855 C-7
C857 D-7
C858 D-7
C860 C-7
C861 B-6
C862 B-7
C866 C-6
C903 E-4
C906 E-4
C907 E-4
C908 E-4
C915 E-5
(S) C917 D-6
C920 D-4
C926 E-4
CN603 F-3
CN802 D-1
D701 E-6
D702 D-3
D704 E-5
D705 E-5
D706 D-1
D708 D-2
D709 D-2
D710 D-2
D711 A-7
D712 C-2
D903 E-4
D904 D-5
IC851 D-7
IC903 F-4
L851 B-7
L852 B-6
L853 B-7
L905 E-4
Q851 D-7
Q852 D-7
Q853 C-7
R701 E-5
R703 D-3
R705 E-5
R706 E-3
R707 E-4
R708 D-2
R711 D-1
R712 E-4
R716 D-1
R717 C-1
R816 D-1
R852 C-7
R853 C-7
Note: (C) mark is CASIO made LCD panel model only.
(S) mark is SHARP made LCD panel model only.
R854 D-7
R858 D-7
R859 D-7
(C) R902 E-4
(S) R903 D-3
R904 D-4
(S) R914 E-4
R938 E-5
R939 F-5
(S) R941 D-6
R942 D-6
(S) R943 E-5
(S) R944 D-4
(S) R960 D-5
(C) R962 E-6
(C) R963 E-6
(S) R964 E-6
(S) R965 D-5
(C) R966 D-6
(S) R967 D-5
(S) R968 D-5
(S) R969 D-5
RV701 A-7
S701 E-5
S702 D-6
S703 E-3
S704 E-4
S705 D-3
S706 D-2
S707 E-3
S708 E-4
S709 D-1
T851 C-7
