MVC-FD73
– 19 –
– 20 –
SECTION 6
REPAIR PARTS LIST
6-1. EXPLODED VIEWS
6-1-2. CABINET (REAR) SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PK-46
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Ref. No. Part No. Description Remark
58 X-3949-575-2 CABINET (REAR) ASSY (Except Brazilian)
58 X-3949-817-1 CABINET (REAR) ASSY (Brazilian)
71 A-7094-351-A PK-46 (CASIO) BOARD, COMPLETE (SERVICE)
71 A-7094-529-A PK-46 (SHARP) BOARD, COMPLETE (SERVICE)
A-7094-351-A PK-46(CASIO) BOARD, COMPLETE (SERVICE)
*********************************
A-7094-529-A PK-46(SHARP) BOARD, COMPLETE (SERVICE)
*********************************
(Ref. No. 2,000 Series)
< BATTERY HOLDER >
BH7011-550-104-32 HOLDER, BATTERY
< BUZZER >
BZ701 1-529-107-11 BUZZER, PIEZOELECTRIC
< CAPACITOR >
C601 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C602 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C603 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C604 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(S) C605 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
C606 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
C702 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C703 1-165-320-11 CERAMIC CHIP 0.47uF 10% 16V
C704 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C705 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C801 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C802 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C803 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C804 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C806 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C807 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C808 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(S) C810 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C811 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND : Canadian model
HK : Hong Kong model
AUS : Australian model
JE : Tourist model
• Due to standardization, replacements in the parts
list may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
Note:
When indicating parts by reference
number, please include the board
name.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
C812 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C813 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C814 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
(S) C815 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C851 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(S) C852 1-113-981-11 TANTAL. CHIP 22uF 20% 20V
C853 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C854 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C855 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C856 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C857 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C858 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C859 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C861 1-104-911-11 TANTAL. CHIP 33uF 20% 10V
C862 1-164-346-11 CERAMIC CHIP 1uF 16V
C863 1-164-661-11 CERAMIC CHIP 0.018uF 10% 50V
C865 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
! C866 1-113-521-91 CERAMIC CHIP 12PF 10% 3KV
C867 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(C) C901 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C902 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C903 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C904 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
(C) C905 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
(S) C905 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C906 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C908 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C909 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C911 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C913 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C915 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
(S) C916 1-113-994-11 TANTAL. CHIP 6.8uF 20% 16V
(S) C917 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C918 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C919 1-107-689-21 TANTAL. CHIP 1uF 20% 35V
C920 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
(C) C921 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C926 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN6011-764-526-11 CONNECTOR, FFC/FPC 18P
* CN602 1-750-075-11 CONNECTOR, FFC/FPC 10P
CN6031-778-598-21 CONNECTOR, BOARD TO BOARD 60P
CN8021-764-526-11 CONNECTOR, FFC/FPC 18P
CN8511-573-929-21 CONNECTOR, FFC/FPC (ZIF) 20P
CN9011-691-388-11 CONNECTOR, FFC/FPC (ZIF) 24P
< DIODE >
D701 8-719-061-82 DIODE TLSU1002(TPX1,SONY)(ACCESS)
D702 8-719-061-81 DIODE TLYU1002(TPX1,SONY)
(FLASH CHARGE)
D852 8-719-073-01 DIODE MA111-(K8).S0
D853 8-719-073-01 DIODE MA111-(K8).S0
D854 8-719-073-01 DIODE MA111-(K8).S0
D903 8-713-102-80 DIODE 1T369-01-T8A
D904 8-719-976-96 DIODE MA8047-H-TX
< IC >
IC601 8-759-535-05 IC BH9530KS2
IC801 8-759-530-19 IC MB40D001PFV-G-BND-ER
IC802 8-759-539-27 IC IR3Y37A4
IC851 8-759-521-35 IC TL5001CDR
IC852 8-759-075-70 IC TA75S393F-TE85R
(S) IC901 8-759-495-00 IC LZ9GH184
(C) IC901 8-759-530-20 IC CM7017L3-T4
IC902 8-759-327-01 IC NJM062V(TE2)
(C) IC903 8-759-523-03 IC TC74HC4066AFT(EL)
(S) IC903 8-759-066-58 IC TC74HC4066AFS-EL
< COIL >
L601 1-414-394-11 INDUCTOR 2.2uH
L701 1-216-296-91 SHORT 0
(S) L701 1-412-067-21 INDUCTOR CHIP 330uH
L801 1-414-402-11 INDUCTOR 47uH
L802 1-414-078-11 INDUCTOR 10uH
L851 1-414-396-21 INDUCTOR 4.7uH
L852 1-424-674-11 INDUCTOR 22uH
L853 1-409-536-41 INDUCTOR 150uH
L901 1-414-754-11 INDUCTOR 10uH
L902 1-414-754-11 INDUCTOR 10uH
L903 1-412-951-11 INDUCTOR 10uH
(C) L904 1-414-754-11 INDUCTOR 10uH
L905 1-412-953-11 INDUCTOR 15uH
< TRANSISTOR >
Q701 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q702 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q851 8-729-042-72 TRANSISTOR UN9214J-(K8).SO
Q852 8-729-042-59 TRANSISTOR UN9112J-(K8).SO
Q853 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q854 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q855 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q856 8-729-823-84 TRANSISTOR FP102-TL
Q857 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q858 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q859 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q860 8-729-039-43 TRANSISTOR FP216-TL
Q862 8-729-042-59 TRANSISTOR UN9112J-(K8).SO
Q903 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q904 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
Q905 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q906 8-729-420-24 TRANSISTOR 2SB1218A-QRS-TX
< RESISTOR >
R601 1-216-033-00 METAL CHIP 220 5% 1/10W
R602 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R603 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R604 1-216-845-11 METAL CHIP 100K 5% 1/16W
R605 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R606 1-218-707-11 RES,CHIP 4.3K 5% 1/16W
R607 1-218-707-11 RES,CHIP 4.3K 5% 1/16W
R608 1-216-864-11 METAL CHIP 0 5% 1/16W
R610 1-216-864-11 METAL CHIP 0 5% 1/16W
R612 1-218-851-11 RES,CHIP 1.5K 0.50% 1/16W
R613 1-218-869-11 RES,CHIP 8.2K 0.50% 1/16W
R614 1-218-863-11 RES,CHIP 4.7K 0.50% 1/16W
R615 1-218-859-11 RES,CHIP 3.3K 0.50% 1/16W
R618 1-218-887-11 RES,CHIP 47K 0.50% 1/16W
R619 1-218-849-11 RES,CHIP 1.2K 0.50% 1/16W
R620 1-216-821-11 METAL CHIP 1K 5% 1/16W
R621 1-218-847-11 RES,CHIP 1K 0.50% 1/16W
R622 1-218-875-11 RES,CHIP 15K 0.50% 1/16W
R623 1-218-292-11 RES,CHIP 20K 5% 1/16W
R624 1-216-817-11 METAL CHIP 470 5% 1/16W
R625 1-216-833-91 RES,CHIP 10K 5% 1/16W
R626 1-216-835-11 METAL CHIP 15K 5% 1/16W
R627 1-216-833-91 RES,CHIP 10K 5% 1/16W
R628 1-216-835-11 METAL CHIP 15K 5% 1/16W
R629 1-216-835-11 METAL CHIP 15K 5% 1/16W
R630 1-216-833-91 RES,CHIP 10K 5% 1/16W
R631 1-216-857-11 METAL CHIP 1M 5% 1/16W
R632 1-216-833-91 RES,CHIP 10K 5% 1/16W
R701 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R702 1-216-819-11 METAL CHIP 680 5% 1/16W
R703 1-216-819-11 METAL CHIP 680 5% 1/16W
R705 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R706 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R707 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R708 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R709 1-216-851-11 METAL CHIP 330K 5% 1/16W
R710 1-216-847-11 METAL CHIP 150K 5% 1/16W
R711 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R712 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R713 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R714 1-216-815-11 METAL CHIP 330 5% 1/16W
R715 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R716 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
(C) R717 1-216-841-11 METAL CHIP 47K 5% 1/16W
R801 1-216-864-11 METAL CHIP 0 5% 1/16W
Note: (C) mark is CASIO made LCD panel model only.
(S) mark is SHARP made LCD panel model only.
Note: (C) mark is CASIO made LCD panel model only.
(S) mark is SHARP made LCD panel model only.
Ref. No. Part No. Description Remark
LCD901 1-803-036-21 INDICATOR MODULE, LIQUID CRYSTAL (SHARP)
LCD901 1-803-184-21 INDICATOR MODULE, LIQUID CRYSTAL (CASIO)
