Sony MVC-FD73

1
CORRECTION-2
File this correction with the service manual.
(99-026)
SERVICE MANUAL
CORRECTION OF FLANGE BACK ADJUSTMENT AND
PICTURE FRAME ADJUSTMENT
MVC-FD73
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Chinese Model
Hong Kong Model
Brazilian Model
Tourist Model
INCORRECT CORRECT
Sony Corporation
Personal VIDEO Products Company
9-974-152-92
2000A0969-1
Printed in Japan ©2000.01
Published by Safety & Service Engineering Dept.
(Page : 5-5)
2. Flange back adjustment
The flange back of inner focus lens is adjusted auto-matically. If
shifted, the AUTO FOCUS and MANUAL FOCUS aredisordered.
6) Set data: 27 to page: 2, address: 01, and press the PAUSE button
on the adjustment remote commander.
(The adjustment data are automatically entered to page: F,
address: B6 to BB, BE to C5.)
(Page : 5-6)
3. Flange back check
Checking procedure:
4) Adjust the just focus in the AUTO FOCUS.
4. Picture frame setting
Switch setting:
1) AUTO FOCUS/MANUAL ........... AUTO FOCUS
(Page : 5-5)
2. Flange back adjustment
The flange back of inner focus lens is adjusted auto-matically.
6) Set data: 15 to page: 2, address: 01, and press the PAUSE button
on the adjustment remote commander.
(The adjustment data are automatically entered to page: F,
address: B6 to BB, BE to C5.)
(Page : 5-6)
3. Flange back check
Checking procedure:
4) Adjust the focus using the focus knob.
4. Picture frame setting
Switch setting:
1)
: Points deleted parts
: Points changed parts
1999.12
