258
Applying Special Effects (Effects on the Overall Video Signal)
Chapter 11 DME Operations
Masking the Posterization or Solarization
effect with a selected pattern
Press [Mask] to display the Mask menu, and set the pattern
type and modifiers (see page 261).
Nega Settings
Applying the Nega effect
1
In the DME menu, select VF2 ‘Video Modify’ and
HF3 ‘Color Modify.’
The Color Modify menu appears.
2
Press [Nega Y] or [Nega C], turning it on, or press both
buttons, turning them on.
Nega Y: Reverse the luminance.
Nega C: Reverse the chroma.
Masking the Nega effect with a selected
pattern
Press [Mask] to display the Mask menu, and set the pattern
type and modifiers (see page 261).
Contrast Settings
Applying the Contrast effect
1
In the DME menu, select VF2 ‘Video Modify’ and
HF3 ‘Color Modify.’
The Color Modify menu appears.
2
Press [Contrast], turning it on.
3
Set the parameters.
Clip, Gain, Offset
Masking the Contrast effect with a
selected pattern
Press [Mask] to display the Mask menu, and set the pattern
type and modifiers (see page 261).
Mosaic Settings
Applying the Mosaic effect
1
In the DME menu, select VF2 ‘Video Modify’ and
HF4 ‘Mosaic.’
The Mosaic menu appears.
2
Press [Mosaic], turning it on.
3
Set the following parameters.
a) Specify minus values to stretch the tiles in the vertical direction, and
plus values to stretch the tiles in the horizontal direction.
Masking the Mosaic effect with a selected
pattern
Press [Mask] to display the Mask menu, and set the pattern
type and modifiers (see page 261).
Sketch Settings
Applying the Sketch effect
1
In the DME menu, select VF7 ‘Enhanced Video
Modify’ and HF1 ‘Sketch.’
The Sketch menu appears.
2
Press [Sketch], turning it on.
Knob Parameter Adjustment Setting values
1 Y Clip Luminance
clip level
+109.59 to –7.31
2 Y Gain Luminance
contrast
gradient
–100.00 to +100.00
3 Y Offset Luminance
offset level
increment
–100.00 to +100.00
4C GainChroma
contrast
gradient
–100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Size Size of tiles 0.00 to 100.00
2 Aspect Aspect ratio
of tiles
–100.00 to
+100.00
a)
Video output level
Video input level
Video output level
Video input level
To Next Page
