3
NW-E002F/E003F/E005F
Fig-1
Fig-2
NOTES ON ARRANGE THE OEL MODULE FLEXIBLE CABLE
pre-fold
SHEET (OEL-FPC), ADHESIVE
Remove protection sheet.
folding line
segment portion
SPACER (OEL)
1. Pre-fold the flexible cable as in Fig-1.
3. Make sure it does not cover the segment portion as in Fig-2.
2. Affix at the center of folding line and remove release SHEET (OEL-FPC), ADHESIVE.
Fold and press fit at the area of SHEET (OEL-FPC), ADHESIVE.
Remove protection sheet from OLED.
3mm
4.5mm
TABLE OF DESTINATION AND COLOR VARIATION
USNW-E002F
NW-E003F
BLACK SILVER PINK VIOLET GREEN BLUE
CND
AEP
E
KR
MX
US
CND
AEP
CEV
E
KR
MX
CEV
CN
JE
JE
CN
NW-E005F US
CND
E
KR
MX
JE
CN
• Abbreviation
CEV : Poland, Czech, Greece and Turkey models
CN : Chinese model
CND : Canadian model
KR : Korean model
MX : Mexican model
JE : Tourist model
Ver. 1.4
