30
NW-E002F/E003F/E005F
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Accessories are given in the last of this parts
list.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
X-2109-806-1 MAIN BOARD, COMPLETE (E002F: AEP)
X-2109-807-1 MAIN BOARD, COMPLETE (E002F: US, CND)
X-2109-808-1 MAIN BOARD, COMPLETE (E002F: CN)
X-2109-809-1 MAIN BOARD, COMPLETE (E002F: E, KR, JE)
X-2109-810-1 MAIN BOARD, COMPLETE (E002F: CEV, MX)
X-2109-811-1 MAIN BOARD, COMPLETE (E003F: AEP)
X-2109-812-1 MAIN BOARD, COMPLETE (E003F: US, CND)
X-2109-813-1 MAIN BOARD, COMPLETE (E003F: CN)
X-2109-814-1 MAIN BOARD, COMPLETE (E003F: E, KR, JE)
X-2109-815-1 MAIN BOARD, COMPLETE (E003F: CEV, MX)
X-2109-817-1 MAIN BOARD, COMPLETE (E005F: US, CND)
X-2109-818-1 MAIN BOARD, COMPLETE (E005F: E, KR, JE)
X-2109-819-1 MAIN BOARD, COMPLETE (E005F: MX)
X-2148-167-1 MAIN BOARD, COMPLETE (E005F: CN)
********************
< CAPACITOR >
C101 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C102 1-125-777-11 CERAMIC CHIP 0.1uF 10% 6.3V
C103 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C104 1-125-777-11 CERAMIC CHIP 0.1uF 10% 6.3V
C105 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C106 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C107 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C108 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C109 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C110 1-128-617-91 CERAMIC CHIP 100PF 5% 25V
C111 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C114 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C115 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C116 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C118 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C119 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C120 1-125-777-11 CERAMIC CHIP 0.1uF 10% 6.3V
C123 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C124 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C125 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C126 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C127 1-114-169-21 CAP, TANTALUM ELECT 220MF
C128 1-114-169-21 CAP, TANTALUM ELECT 220MF
C129 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C130 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C132 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C133 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C134 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C136 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C137 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C138 1-125-777-11 CERAMIC CHIP 0.1uF 10% 6.3V
C139 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C140 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C141 1-125-777-11 CERAMIC CHIP 0.1uF 10% 6.3V
C142 1-100-735-91 CERAMIC CHIP 10uF 20% 4V
C143 1-112-692-11 CERAMIC CHIP 1000PF 5% 50V
C144 1-128-617-91 CERAMIC CHIP 100PF 5% 25V
C145 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C146 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C147 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C148 1-125-777-11 CERAMIC CHIP 0.1uF 10% 6.3V
C149 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C150 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C152 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C153 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C154 1-100-735-91 CERAMIC CHIP 10uF 20% 4V
C155 1-164-845-11 CERAMIC CHIP 5PF 0.25PF 50V
C156 1-164-845-11 CERAMIC CHIP 5PF 0.25PF 50V
C159 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C162 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C201 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C401 1-100-735-91 CERAMIC CHIP 10uF 20% 4V
C402 1-164-931-11 CERAMIC CHIP 100PF 10% 50V
C403 1-114-170-91 CAP, CHIP TANTALUM ELECT 1MF
C405 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C406 1-114-170-91 CAP, CHIP TANTALUM ELECT 1MF
C407 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C408 1-114-155-21 CAP, TANTALUM ELECT 2.2MF
C409 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C501 1-128-632-91 CERAMIC CHIP 0.01uF 10% 6.3V
C601 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C602 1-112-815-91 CERAMIC CHIP 10uF 20% 6.3V
C603 1-112-815-91 CERAMIC CHIP 10uF 20% 6.3V
C604 1-131-664-91 CERAMIC CHIP 0.15uF 10% 10V
C605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C606 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C607 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C608 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C609 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C610 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C613 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C614 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C615 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C616 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C617 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C619 1-114-176-21 CAP, TANTALUM ELECT 47MF
When indicating parts by reference number,
please include the board name.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
R R
Parts of Color Cabinet’s Color
•Abbreviation
CEV : Poland, Czech, Greece and
Turkey models
CN : Chinese model
CND : Canadian model
KR : Korean model
MX : Mexican model
JE : Tourist model
MAIN
Ver. 1.3
To Next Page
