NW-E002F/E003F/E005F
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R507 1-240-726-91 METAL CHIP 470K 5% 1/20W
R508 1-240-711-91 METAL CHIP 22K 5% 1/20W
R509 1-240-714-91 METAL CHIP 47K 5% 1/20W
R510 1-240-707-91 METAL CHIP 10K 5% 1/20W
R511 1-240-726-91 METAL CHIP 470K 5% 1/20W
R512 1-240-726-91 METAL CHIP 470K 5% 1/20W
R513 1-240-718-91 METAL CHIP 100K 5% 1/20W
R514 1-240-707-91 METAL CHIP 10K 5% 1/20W
R515 1-218-965-11 RES-CHIP 10K 5% 1/16W
R601 1-218-990-81 SHORT CHIP 0
R602 1-218-985-11 RES-CHIP 470K 5% 1/16W
R603 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R604 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R605 1-218-990-81 SHORT CHIP 0
R610 1-218-985-11 RES-CHIP 470K 5% 1/16W
R611 1-218-985-11 RES-CHIP 470K 5% 1/16W
R613 1-218-965-11 RES-CHIP 10K 5% 1/16W
R614 1-208-702-11 METAL CHIP 6.2K 0.5% 1/16W
R616 1-218-990-81 SHORT CHIP 0
R617 1-218-990-81 SHORT CHIP 0
R619 1-218-990-81 SHORT CHIP 0
R621 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R626 1-218-990-81 SHORT CHIP 0
R627 1-218-990-81 SHORT CHIP 0
R629 1-218-985-11 RES-CHIP 470K 5% 1/16W
R631 1-218-985-11 RES-CHIP 470K 5% 1/16W
R633 1-218-990-81 SHORT CHIP 0
R634 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R635 1-218-985-11 RES-CHIP 470K 5% 1/16W
R801 1-218-990-81 SHORT CHIP 0
R802 1-218-985-11 RES-CHIP 470K 5% 1/16W
R803 1-218-965-11 RES-CHIP 10K 5% 1/16W
R1301 1-218-985-11 RES-CHIP 470K 5% 1/16W
(E005F)
R1301 1-218-990-81 SHORT CHIP 0 (E003F)
R1302 1-218-985-11 RES-CHIP 470K 5% 1/16W
(E003F/E005F)
R1303 1-218-977-11 RES-CHIP 100K 5% 1/16W
(E005F)
R1303 1-218-990-81 SHORT CHIP 0 (E003F)
R1304 1-218-990-81 SHORT CHIP 0 (E005F)
R1305 1-218-977-11 RES-CHIP 100K 5% 1/16W
(E003F/E005F)
R1306 1-218-990-81 SHORT CHIP 0 (E005F)
R2106 1-208-705-11 METAL CHIP 8.2K 0.5% 1/16W
R2107 1-208-705-11 METAL CHIP 8.2K 0.5% 1/16W
R2115 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R2701 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R2702 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R2704 1-218-990-81 SHORT CHIP 0
R2705 1-218-939-11 RES-CHIP 68 5% 1/16W
R2706 1-218-953-11 RES-CHIP 1K 5% 1/16W
R2707 1-218-929-11 RES-CHIP 10 5% 1/16W
R2708 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R2709 1-218-985-11 RES-CHIP 470K 5% 1/16W
< SWITCH >
S101 1-786-914-11 SWITCH, TACTILE (RESET)
S501 1-786-914-11 SWITCH, TACTILE (VOL–)
S502 1-786-914-11 SWITCH, TACTILE (VOL+)
S503 1-786-738-11 TACTILE SWITCH (>)
S504 1-786-738-11 TACTILE SWITCH (.)
S505 1-572-922-11 SWITCH, SLIDE (HOLD .)
< VARISTOR >
VDR101 1-805-216-21 VARISTOR, CHIP
VDR102 1-805-216-21 VARISTOR, CHIP
VDR103 1-805-216-21 VARISTOR, CHIP
VDR104 1-805-216-21 VARISTOR, CHIP
VDR105 1-803-742-21 VARISTOR, CHIP
VDR106 1-803-742-21 VARISTOR, CHIP
VDR107 1-805-216-21 VARISTOR, CHIP
VDR108 1-805-216-21 VARISTOR, CHIP
VDR301 1-805-216-21 VARISTOR, CHIP (E003F/E005F)
VDR501 1-805-216-21 VARISTOR, CHIP
VDR601 1-803-742-21 VARISTOR, CHIP
VDR602 1-803-742-21 VARISTOR, CHIP
VDR604 1-803-742-21 VARISTOR, CHIP
VDR606 1-805-216-21 VARISTOR, CHIP
< VIBRATOR >
X101 1-795-752-21 VIBRATOR, CRYSTAL 12MHz
X102 1-813-793-21 VIBRATOR, CERAMIC 45.1584MHz
X801 6-600-517-01 IC RX-4574LC
************************************************************
SWITCH BOARD
(including CABINET (MID) ASSY)
*************
< SWITCH >
S901 1-786-650-41 SWITCH, TACTILE (Nx)
S902 1-786-914-11 SWITCH, TACTILE (
HOME
)
< VARISTOR >
VDR901 1-805-216-21 VARISTOR, CHIP
VDR902 1-805-216-21 VARISTOR, CHIP
************************************************************
MISCELLANEOUS
**************
26 1-802-022-21 INDICATOR MODULE, ORGANIC EL
BT901 1-756-663-11 BATTERY, SECONDARY (EXCEPT US, CND)
BT901 X-2109-825-1 BATTERY (A) ASSY (US, CND)
ACCESSORIES
***********
2-678-175-11 QUICK START GUIDE (ENGLISH)
(EXCEPT US)
2-678-175-21 QUICK START GUIDE (FRENCH)
(CND, AEP, CEV)
2-678-175-31 QUICK START GUIDE (GERMAN) (AEP, CEV)
2-678-175-41 QUICK START GUIDE (SPANISH)
(AEP, CEV, MX)
2-678-175-51 QUICK START GUIDE (ITALIAN) (AEP, CEV)
