SERVICE MANUAL
Ver. 1.5 2006.11
SUPPLEMENT-1
Subject: MAIN board changed to 1-870-341-12 from 1-870-341-11
on part number
9-887-213-81
NW-E002F/E003F/E005F
US Model
Canadian Model
NW-E002F/E003F/E005F
AEP Model
NW-E002F/E003F
E Model
Chinese Model
Tourist Model
NW-E002F/E003F/E005F
Part number of printed wiring board changed to 1-870-341-12 from 1-870-341-11.
It has any difference between part mumber 1-870-341-12 and part number 1-870-341-11.
This supplement-1 describes the difference in the two boards.
Refer to original service manual (9-887-213-0[]) for other information.
IC101
MAIN BOARD (SIDE A)
TH101
TH101
no mount : MAIN BOARD part number 1-870-341-11 (for ORIGINAL SERVICE MANUAL)
mount : MAIN BOARD part number 1-870-341-12 (for SUPPLEMENT-1)
IC1301
•How to distinguish
