6-2 Channels Section Panels
The Routing panels allow signals to be routed to Multitrack busses, the
Main Output Bus and the Super Send Groups. Multi-Format routing and
its monitor are also set using this panel.
MULTI-FORMAT Section
1 MULTI-FORMAT L, L/C, C, R/C, R, L-S, SUB, R-S Push-Buttons
These allow surround routing for a number of sources. Their function is
set depending on which function is selected to the faders in the channels
section.
6-2-8 Routing Panel
ROUTING panel
3
4
1
2
6
7
5
8
