Sony PDW-680 - Audio Performance; Camera Section

Specifications
22
SDI Output
BNC (×2)
SDI OUT 1 (HD/SD switchable);
HD-SDI: SMPTE 292M (with
embedded audio)
SD-SDI: SMPTE 259M (with
embedded audio)
SDI OUT 2 (HD/SD switchable,
character on/off);
HD-SDI: SMPTE 292M (with
embedded audio)
SD-SDI: SMPTE 259M (with
embedded audio)
Audio Output
CH-1/CH-2: XLR-type 5-pin (male,
stereo) (×1)
Timecode Output
BNC (×1), 1.0 Vp-p, 75 Ω
Earphone Output
Mini-jack (×2);
front: monaural
rear: stereo/monaural
Speaker Output
Monaural
DC Input
XLR-type 4-pin (male) (×1), 11 V to
17 V
DC Output
4-pin (×1) (for wireless microphone
receiver),
11 V to 17 V DC (MAX 0.5 A)
Lens
12-pin
Remote
8-pin
Light
2-pin, DC 12 V, max. 50 W
i.LINK
IEEE1394, 6-pin (×1), File Access
Mode
Memory Stick
(×1) for camera setup files
Ethernet
RJ-45 (×1),
100BASE-TX: IEEE 802.3u,
10BASE-T: IEEE 802.3
USB
(×1) for connection to peripheral
devices/version upgrade
Frequency Response
20 Hz to 20 kHz, +0.5 dB/–1.0 dB
Dynamic Range
More than 93 dB
Distortion
Less than 0.08% (at 1 kHz, reference
level)
Crosstalk
Less than –70 dB (at 1 kHz, reference
level)
Wow and Flutter
Below measurable limit
Headroom
12/16/18/20 dB (selectable)
Imager
3-chip
2
/
3
-type HD “Exmor” CMOS
Effective Picture Elements
1920 (H) × 1080 (V)
Optical System
F1.4 prism system
Built-in Optical Filters
1: Clear
2:
1
/
4
ND
3:
1
/
16
ND
4:
1
/
64
ND
Shutter Speed (Time)
59.94i:
1
/
100
,
1
/
125
,
1
/
250
,
1
/
500
,
1
/
1000
.
1
/
2000
,
ECS , SLS
Audio Performance
Camera Section
