– 24 –
1
four screws
(2.6
×
16)
2
optical pick-up section
2
two screws
(P 3
×
30)
1
two screws
(BVTP 3
×
10)
4
connector
(CNP505)
3
front (SP) section
OPTICAL PICK-UP SECTION
FRONT (SP) SECTION
