Setup Menu List
91
Menu Configuration and Detailed Settings
Marker
Setting the
markers added to
pictures on the
LCD monitor/EVF
screen
[M]
Setting
On / Off
Turn all marker indications on/off in combination.
Safety Zone
On / Off
Turn the safety marker on/off.
Safety Area
80% / 90% / 92.5% / 95%
Select the size (ratio to the entire screen) of the safety zone
marker.
Center Marker
On / Off
Turn the center marker on/off.
Aspect Marker
Line / Mask / Off
Select the aspect marker.
Line: To show white lines
Mask: To lower the video signal level of areas outside the
marker range.
Off: To not display
Note
No aspect marker is displayed when a video format of EC
(Edge Crop) is selected in SD Mode.
Aspect Select
4:3 / 13:9 / 14:9 / 15:9 / 1.66:1 /
1.85:1 / 2.35:1 / 2.4:1
Select the ratio of the aspect marker.
Aspect Mask
90% / 80% / 70% / 60% / 50% /
40% / 30% / 20% / 10% / 0%
When “Aspect Marker” is “Mask,” select the brightness of
images outside the aspect marker.
Guide Frame
On / Off
Turn the guide frame marker on/off.
Zebra
Setting the zebra
pattern
[M]
Setting
On / Off
Turn the zebra function on/off.
Zebra Select
1 / 2 / Both
Select the zebra pattern(s) to be displayed.
1: To display only Zebra1 (the default is 70%) for an area
within ±10% of the “Zebra1 Level” video level.
2: To display only Zebra2 (the default is 100%) for a video
level over 100%.
Both: To display both zebra 1 and zebra 2
Zebra1 Level
50 to 107 (70)
Set the display level of zebra 1.
Display On/Off
Selecting the items
to be displayed on
the LCD monitor/
EVF screen
[M]
Video Level Warnings
On / Off
Turn the warning indication to be displayed when the picture
is too bright or too dark on/off.
Sending Clip Info (PMW-200 only)
On / Off
Turn the uploading status of a clip when connecting the CBK-
WA100 Wireless Adapter on/off.
Brightness Display
On / Off
Turn the numeric indication to show the picture brightness on/
off.
Histogram Display
On / Off
Turn the histogram indication to show the level distribution of
the picture on/off.
Lens Info
Meter / Feet / Off
Select the depth-of-field indication.
Meter: To indicate in meters
Feet: To indicate in feet
Off: To not indicate
Zoom Position
Number / Bar / Off
Select the type of zoom position indication.
Number: Indication with a number
Bar: Indication with a bar
Off: To not display
LCD/VF SET
Menu items Subitems and setting values Contents
