Sony PS-J10 - Section 4 Electrical Parts List

– 9 –
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
CND: Canadian model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may have
some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
SECTION 4
ELECTRICAL PARTS LIST
Note:
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-654-481-11 EQ BOARD
********
< CAPACITOR >
C301 1-124-903-11 ELECT 1uF 20% 50V
C302 1-124-903-11 ELECT 1uF 20% 50V
C303 1-104-664-11 ELECT 47uF 20% 16V
C304 1-102-978-00 CERAMIC 220PF 5% 50V
C305 1-102-978-00 CERAMIC 220PF 5% 50V
C306 1-126-963-11 ELECT 4.7uF 20% 50V
C307 1-126-963-11 ELECT 4.7uF 20% 50V
C308 1-130-475-00 MYLAR 0.0022uF 5% 50V
C309 1-130-475-00 MYLAR 0.0022uF 5% 50V
C310 1-130-482-00 MYLAR 0.0082uF 5% 50V
C311 1-130-482-00 MYLAR 0.0082uF 5% 50V
C312 1-126-962-11 ELECT 3.3uF 20% 50V
C313 1-126-962-11 ELECT 3.3uF 20% 50V
C314 1-104-664-11 ELECT 47uF 20% 16V
C315 1-101-005-00 CERAMIC 22000PF 50V
< IC >
IC301 8-759-989-89 IC BA4558N
< TRANSISTOR >
Q301 8-729-020-80 TRANSISTOR 2SC2235-OY
< RESISTOR >
R301 1-247-823-31 CARBON 470 5% 1/4W
R302 1-247-823-31 CARBON 470 5% 1/4W
R303 1-249-441-11 CARBON 100K 5% 1/4W
R304 1-249-441-11 CARBON 100K 5% 1/4W
R305 1-249-441-11 CARBON 100K 5% 1/4W
R306 1-249-441-11 CARBON 100K 5% 1/4W
R307 1-247-855-31 CARBON 10K 5% 1/4W
R308 1-249-417-11 CARBON 1K 5% 1/4W F
R309 1-249-417-11 CARBON 1K 5% 1/4W F
R310 1-247-823-31 CARBON 470 5% 1/4W
R311 1-247-823-31 CARBON 470 5% 1/4W
R312 1-249-435-11 CARBON 33K 5% 1/4W
R313 1-249-435-11 CARBON 33K 5% 1/4W
R314 1-247-893-11 CARBON 390K 5% 1/4W
R315 1-247-893-11 CARBON 390K 5% 1/4W
R316 1-247-881-00 CARBON 120K 5% 1/4W
R317 1-247-881-00 CARBON 120K 5% 1/4W
R318 1-249-417-11 CARBON 1K 5% 1/4W F
R319 1-249-417-11 CARBON 1K 5% 1/4W F
R320 1-247-847-11 CARBON 4.7K 5% 1/4W
< SWITCH >
S301 1-762-223-11 SWITCH, SLIDE (EQ)
< DIODE >
ZD1 8-719-001-15 DIODE UZL-9M2
**************************************************************
* 1-654-480-11 LED BOARD
*********
< DIODE >
L1 8-719-300-71 LED SEL2210R (45)
L2 8-719-300-71 LED SEL2210R (33)
< RESISTOR >
R1 1-249-417-11 CARBON 1K 5% 1/4W F
**************************************************************
* 1-654-912-11 POWER BOARD
***********
< CAPACITOR >
C101 1-126-942-61 ELECT 1000uF 20% 16V
C102 1-104-666-11 ELECT 220uF 20% 16V
< DIODE >
D101 8-719-200-02 DIODE 10E2
D102 8-719-200-02 DIODE 10E2
D103 8-719-200-02 DIODE 10E2
D104 8-719-200-02 DIODE 10E2
D105 8-719-200-02 DIODE 10E2
< RESISTOR >
R101 1-249-410-11 CARBON 270 5% 1/4W
R102 1-249-411-11 CARBON 330 5% 1/4W
< SWITCH >
! S101 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE (E)
POWERLEDEQ
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board
name.
