Sony PS-LX430 - Page 22

102
103
104
105
106
107
108
109
110
111
112
114
113
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
Part No.
4-881-633-00
4-903-333-01
4-844-041-11
7-621-775-80
*4-880-501-00
4-880-503-00
*4-881-659-00
*4-861-940-00
*4-301-647-00
3-703-137-00
4-903-409-01
4-874-250-00
0-056-028-00
4-877-824-00
7-685-152-21
4-852-841-00
7-624-133-54
X-4881-610-0
4-911-107-01
*X-4874-209-0
4-874-259-00
7-624-133-44
4-874-223-00
4-874-231-00
4-874-277-00
3-548-124-00
4-844-041-00
7-685-145-14
*4-903-410-01
*4-876-317-00
4-903-331-01
Description
ON:
(PS-LX431,LX431(N))..... KNOB (I), IFC
(PS-LX430 ,LX430(C) ,LX433)...KNOB, IFC
WASHER, (N)
SCREW +B 2.6X16
LEVER (A), LIFTER
SPRING, COMPRESSION
LEVER (C), LIFTER
SHAFT, LIFTER LEVER
WASHER, SPECIAL, 12
SCREW, TAPPING +PTPWH 3X10
CAM, IFC
SPRING
WASHER, PLAIN, 14 DIA.
CAM, LIFTER
SCREW PTPWH 3X25 TYPE 2
TUBE
STOP RING 10, TYPE-CE
LEVER (C) ASSY, INDEX
POLY-SLIDER (DIA. 9.5) (LARGE)
LEVER (B) ASSY, INDEX
RUBBER, SHOCK ABSORBING
STOP RING 9, TYPE-CE
LEVER (A), ARM
CAM, ECCENTRIC
LEVER (B), ARM
SPRING, TENSION
WASHER, (N)
SCREW +P 3X6 TYPE2 SLIT
RETAINER (C), LIFTER
GUIDE, LIFTER
SPRING (LIFTER), COMPRESSION
Remarks
131
132
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
251
252
253
254
255
256
257
260
PM101
PM201
$601
$701
—23—
Part No.
4-874-275-00
*X-4874-206-0
3-701-509-00
4~812-554-00
7-682-110-01
7-685-755-01
*X-4874-205-0
3-701-441-21
X-4874-204-0
X-4874-203-7
*X-4874-202-0
4-874-234-00
7-622-207-05
7-682-546-04
4-889-523-01
4-909-022-01
7-624-133-34
*4-903-438-01
7-687-202-21
*X-4903-405-1
7-621-741-09
4-876-322-00
4-876-346-00
4~-903-444-4]
*4-909-021-01
3-701-748-00
4-909-084-01
1-454-394-21
1-454-394-21
1-570-489-11
1-570-489-11
Description Remarks
PAD, BRAKE
LEVER ASSY, BRAKE
SET SCREW, DOUBLE CUP 3X8
WASHER
SCREW +P 3X18
SCREW +PTT 3X14 (S)
LEVER ASSY, RESET
WASHER
LEVER ASSY, SIZE
LEVER ASSY, CLUTCH
LEVER ASSY, MAIN
CORE
N 2.6, TYPE 2
SCREW +BVTT 3X5 (S)
SHAFT, CENTER
BEARING (B)
STOP RING 8, TYPE-CE
PLATE, RESET
TOTSU PTPWH 2X4, TYPE 2, SLIT
CHASSIS ASSY
SET-SCT HEX. 2.6X8 WP
SPRING, COMPRESSION (BRAKE)
SPRING, TENSION (RESET)
FRAME
BRACKET, BEARING
CLAMP
NUT, BEARING
SOLENOID, PLUNGER
SOLENOID, PLUNGER
SWITCH, MICRO (ARM,REST) (PLAY)
SWITCH, MICRO (ARM,REST) (PLAY)
