Sony PSOne SCPH-101 - 6 Electrical Parts List

Reproduction prohibited Reproduction prohibited
6-1 6-2
SC Ref. No. Part No. Description Remark
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
METAL:Metal-film resistor.
F:nonflammable
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
When indicating parts by reference
number, please include the board.
NOTE:
• SC Classification :
S : Stocked parts
O : Ordered parts
U : Unsupplied parts
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
SC Ref. No. Part No. Description Remark
SC Ref. No. Part No. Description Remark SC Ref. No. Part No. Description Remark
O0 A-6713-742-A PM-41 BOARD, COMPLETE (100:-11/-21/-31)
O0 A-6713-768-A PM-41 BOARD, COMPLETE (101:-21/-31)
O0 A-6713-776-A PM-41 BOARD, COMPLETE (102:-21/-31)
O0 A-6713-853-A PM-41 BOARD, COMPLETE (100:-41/-51)
O0 A-6713-854-A PM-41 BOARD, COMPLETE (101:-41/-51)
O0 A-6713-855-A PM-41 BOARD, COMPLETE (102:-41/-51)
O0 A-6713-864-A PM-41 BOARD, COMPLETE (103:-41/-51)
O0 A-6713-902-A PM-41 BOARD, COMPLETE (101:-61)
O0 A-6713-903-A PM-41 BOARD, COMPLETE (100:-61)
O0 A-6713-904-A PM-41 BOARD, COMPLETE (102:-61)
O0 A-6713-906-A PM-41 BOARD, COMPLETE (103:-61)
O0 A-6715-470-A PM-41 BOARD, COMPLETE (100:-71)
O0 A-6715-471-A PM-41 BOARD, COMPLETE (101:-71)
O0 A-6715-483-A PM-41 BOARD, COMPLETE (102:-71)
O0 A-6715-484-A PM-41 BOARD, COMPLETE (103:-71)
**********************
< CAPACITOR >
O C007 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-71)
O C008 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(-11/-21)
O C009 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(-11/-21)
O C009 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
(-31/-41/-51/-61/-71)
O C010 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-31/-41/-51/-61/-71)
O C101 1-125-764-41 CERAMIC CHIP 100PFX4 50V
(-11/-21/-31/-41/-51/-61)
O C102 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C104 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C105 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C106 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C109 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C110 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C111 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C112 1-164-156-11 CERAMIC CHIP 0.1uF 25V
O C113 1-164-156-11 CERAMIC CHIP 0.1uF 25V
O C114 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(-11/-21/-31/-41/-51/-61)
O C115 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
O C116 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
O C118 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(-11/-21/-31/-41/-51/-61)
O C122 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C124 1-115-156-11 CERAMIC CHIP 1uF 10V
O C125 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(-71)
O C126 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(-71)
O C127 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(-71)
O C128 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(-71)
O C129 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
O C130 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
O C131 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
O C132 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C133 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C134 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C136 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C137 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(-71)
O C137 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
(-11/-21/-31/-41/-51/-61)
O C138 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C138 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(-11/-21/-31/-41/-51/-61)
O C139 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C139 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(-11/-21/-31/-41/-51/-61)
O C140 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(-11/-21/-31/-41/-51/-61)
O C144 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C145 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C146 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C150 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-11/-21/-31/-41/-51/-61)
O C151 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-11/-21/-31/-41/-51/-61)
O C152 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(-11)
O C152 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-21/-31/-41/-51/-61/-71)
O C153 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(-11)
O C208 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C209 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C211 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(-11/-21/-31/-41/-51)
O C211 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C211 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-61)
O C212 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-11/-21/-31/-41/-51/-71)
O C212 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-61)
O C213 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C214 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C215 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C215 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C216 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(-11/-21/-31/-41/-51)
O C216 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C216 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-61)
O C217 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C217 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C218 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C218 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C219 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C220 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C220 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C221 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C222 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51)
O C223 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C224 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C224 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C225 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51)
O C226 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51)
O C227 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C227 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C228 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C228 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C234 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C234 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C235 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C236 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(-11/-21/-31/-41/-51)
O C236 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C236 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-61)
O C238 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(-11/-21/-31/-41/-51)
O C238 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C238 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-61)
O C239 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
(-11/-21/-31/-41/-51)
O C240 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C240 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C241 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(-11/-21/-31/-41/-51)
O C241 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C241 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-61)
O C242 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C242 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(-11/-21/-31/-41/-51)
O C242 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-61)
O C243 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
