6-5 6-6
SC Ref. No. Part No. Description Remark SC Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
SC Ref. No. Part No. Description Remark
O C715 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
O C720 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
O C724 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
(-11/-21/-31/-41/-51/-61)
O C724 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
(-71)
O C725 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
O C726 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
O C728 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
O C729 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
O C731 1-124-779-00 ELECT CHIP 10uF 20% 16V
(-71)
O C731 1-128-004-11 ELECT CHIP 10uF 20% 16V
(-11/-21/-31/-41/-51/-61)
O C733 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
(-11/-21/-31/-41/-51/-61)
O C736 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
O C737 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
O C738 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
(-11/-21/-31/-41/-51/-61)
O C738 1-165-877-91 TANTAL. CHIP 33uF 20% 6.3V
(-71)
O C739 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
O C740 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
(-11/-21/-31/-41/-51/-61)
O C740 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C741 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
(-11/-21/-31/-41/-51/-61)
O C741 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C742 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
O C743 1-164-156-11 CERAMIC CHIP 0.1uF 25V
O C744 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
O C745 1-164-156-11 CERAMIC CHIP 0.1uF 25V
O C747 1-164-156-11 CERAMIC CHIP 0.1uF 25V
O C748 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C749 1-164-156-11 CERAMIC CHIP 0.1uF 25V
O C752 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C753 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C754 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(-71)
O C755 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
(-71)
O C756 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C757 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C758 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C759 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C760 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C761 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
O C762 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
O C763 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
O C764 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C765 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C767 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C767 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C768 1-115-156-11 CERAMIC CHIP 1uF 10V
(-11/-21/-31/-41/-51/-61)
O C768 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C771 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C772 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-71)
O C773 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-11/-21/-31/-41/-51/-61)
O C774 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(-11/-21/-31/-41/-51/-61)
O C775 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(-11/-21/-31/-41/-51/-61)
O C776 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
< TERMINAL BOARD >
O CN101 1-694-748-11 TERMINAL BOARD (FRONT)
O CN102 1-694-748-11 TERMINAL BOARD (FRONT)
< CONNECTOR >
O CN502 1-779-029-71 CONNECTOR, SQUARE TYPE 12P
(AV MULTI OUT)
O CN701 1-573-290-21 PIN, CONNECTOR (1.5mm) (SMD) 4P
O CN702 1-779-071-21 CONNECTOR, FFC/FPC 16P
< DIODE >
O D002 8-719-976-99 DIODE DTZ5.1B
O D003 8-719-059-94 LED SML-010MT-T86 (I/1)
O D004 8-719-158-49 DIODE RD12S-B2
(-11/-21/-31/-41/-51/-61)
O D101 8-719-066-17 DIODE FTZ6.8E-T148
O D103 8-719-067-59 DIODE MAZ9120D0LS0-TX/L
O D104 8-719-065-68 DIODE MAZF04700LS0
O D503 8-719-067-59 DIODE MAZ9120D0LS0-TX/L
(-11/-21/-31/-41/-51/-61)
O D510 8-719-067-59 DIODE MAZ9120D0LS0-TX/L
(-11/-21/-31/-41/-51/-61)
O D511 8-719-158-49 DIODE RD12S-B2
(-11/-21/-31/-41/-51/-61)
O D601 8-719-060-81 DIODE MA735-TX
(-21/-31/-41/-51/-61/-71)
< ON BOARD CONTACT >
O ET101 1-694-592-31 ON BOARD CONTACT
O ET102 1-694-592-31 ON BOARD CONTACT
(-11/-21/-31/-41/-51/-61)
< FERRITE BEAD >
O FB001 1-469-176-21 INDUCTOR, FERRITE BEAD
(-11/-21/-31/-41/-51/-61)
O FB003 1-469-324-21 FERRITE, EMI (SMD)
(-11/-21/-31/-41/-51/-61)
O FB102 1-469-110-21 FERRITE, EMI (SMD)
O FB117 1-469-667-21 FERRITE, EMI (SMD)
O FB118 1-469-667-21 FERRITE, EMI (SMD)
O FB119 1-469-667-21 FERRITE, EMI (SMD)
O FB120 1-414-760-21 FERRITE, EMI (SMD)
O FB121 1-414-760-21 FERRITE, EMI (SMD)
O FB122 1-414-760-21 FERRITE, EMI (SMD)
O FB123 1-469-667-21 FERRITE, EMI (SMD)
O FB124 1-216-864-11 METAL CHIP 0 5% 1/16W
O FB401 1-500-113-22 BEAD, FERRITE (CHIP)
(-11/-21/-31/-41/-51/-61)
O FB402 1-500-113-22 BEAD, FERRITE (CHIP)
(-11/-21/-31/-41/-51/-61)
O FB501 1-550-907-21 BEAD, FERRITE (CHIP)
O FB502 1-500-113-22 BEAD, FERRITE (CHIP)
(-11/-21/-31/-41/-51/-61)
O FB503 1-500-113-22 BEAD, FERRITE (CHIP)
(-11/-21/-31/-41/-51/-61)
O FB601 1-414-813-11 FERRITE, EMI (SMD)
O FB602 1-469-324-21 FERRITE, EMI (SMD)
(-11/-21/-31/-41/-51/-61)
O FB701 1-469-324-21 FERRITE, EMI (SMD)
(-11/-21/-31/-41/-51/-61)
O FB702 1-469-324-21 FERRITE, EMI (SMD)
(-11/-21/-31/-41/-51/-61)
O FB703 1-469-324-21 FERRITE, EMI (SMD)
(-11/-21/-31/-41/-51/-61)
O FB704 1-469-324-21 FERRITE, EMI (SMD)
(-11/-21/-31/-41/-51/-61)
O FB710 1-216-864-11 METAL CHIP 0 5% 1/16W
(-11/-21/-31/-41/-51/-61)
< IC >
S IC002 8-759-197-94 IC M51957BFP-600D (-11/-21)
S IC003 8-759-824-75 IC RN5VD13AA-TL (-31/-41/-51/-61/-71)
S IC102 6-800-362-01 IC MSM534031E-45GS-KPR2 (100)
S IC102 6-800-363-01 IC MSM534031E-46GS-KPR2 (101/103)
S IC102 6-800-364-01 IC MSM534031E-47GS-KPR2 (102)
S IC103 8-759-387-16 IC CXD8606Q
S IC106 8-759-377-18 IC TC51V18325BJ-60S(YE)
S IC201 8-759-369-81 IC KM4132G271Q-12 (-11/-21/-31)
S IC201 8-759-684-14 IC K4G163222A-PC70 (-41/-51)
S IC203 8-759-366-69 IC CXD8561Q (-11/-21/-31/-41/-51)
S IC203 8-759-656-47 IC CXD9500Q (-61/-71)
S IC204 8-759-496-22 IC CY2081SL-500T (NTSC)
S IC204 8-759-496-23 IC CY2081SL-509T (PAL)
S IC205 8-759-837-19 IC MM1562FFBE (-61)
S IC304 6-800-550-01 IC MC68HC05G6PB-SC430947PBEB1
(100:-71,103:-71)
S IC304 6-800-551-01 IC MC68HC05G6PB-SC430948PBEB1
(102:-71)
S IC304 6-800-552-01 IC MC68HC05G6PB-SC430949PBEB1
(101:-71)
S IC304 8-759-598-55 IC MC68HC05G6-SC430942PBEB1
(100:-11/-21/-31/-41/-51/-61,
103:-41/-51/-61)
S IC304 8-759-598-56 IC MC68HC05G6-SC430943PBEB1
(102:-21/-31/-41/-51/-61)
S IC304 8-759-598-57 IC MC68HC05G6-SC430944PBEB1
(101:-21/-31/-41/-51/-61)
S IC310 8-759-342-01 IC MB814260-70PJER
(-11/-21/-31/-41/-51/-61)
S IC405 6-700-780-01 IC NJM2790V(TE2) (-71)
S IC405 8-759-598-10 IC NJM2174V(TE2) (-11/-21/-31/-41/-51/-61)
S IC502 8-752-086-02 IC CXA2106R-T4
S IC601 8-759-391-69 IC MC78M05CDTRK
S IC602 8-759-598-12 IC LP2985IM5X-3.5 (-11/-21/-31/-41/-51/-61)
S IC603 8-759-691-04 IC BA00AST (-11)
S IC604 8-759-643-48 IC BA00ASFP-E2 (-11)
S IC606 8-759-346-78 IC TL594CD-R2 (-21)
S IC607 8-759-680-31 IC TL594CPWR (-31/-41/-51/-61/-71)
S IC608 8-759-837-19 IC MM1562FFBE (-71)
S IC722 8-759-677-90 IC BA5947FP-E2
S IC723 8-752-087-83 IC CXA2575N-T4
S IC732 8-752-395-18 IC CXD2938Q (-11/-21/-31/-41/-51/-61)
S IC732 8-752-415-88 IC CXD2941R (-71)
< JACK >
O0 J001 1-695-565-11 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 7.5V)
< COIL >
O L104 1-412-052-21 INDUCTOR 1uH
O L105 1-412-052-21 INDUCTOR 1uH (-71)
O L106 1-412-052-21 INDUCTOR 1uH
(-11/-21/-31/-41/-51/-61)
O L203 1-469-667-21 FERRITE, EMI (SMD)
O L304 1-412-951-11 INDUCTOR 10uH
(-11/-21/-31/-41/-51/-61)
O L401 1-412-951-11 INDUCTOR 10uH
(-11/-21/-31/-41/-51/-61)
O L601 1-412-052-21 INDUCTOR 1uH
O L602 1-412-052-21 INDUCTOR 1uH
(-21/-31/-41/-51/-61/-71)
O L603 1-424-674-11 INDUCTOR 22uH
(-21/-31/-41/-51/-61/-71)
O L604 1-412-052-21 INDUCTOR 1uH
(-11/-21/-31/-41/-51/-61)
SC Ref. No. Part No. Description Remark
