Sony PSOne SCPH-101 - Page 32

Reproduction prohibited Reproduction prohibited
6-9 6-10
SC Ref. No. Part No. Description Remark SC Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
O R792 1-218-727-11 RES-CHIP 30K 5% 1/16W
(-71)
O R793 1-216-845-11 METAL CHIP 100K 5% 1/16W
O R795 1-216-833-11 METAL CHIP 10K 5% 1/16W
O R901 1-216-295-91 SHORT 0 (101)
O R902 1-216-295-91 SHORT 0 (102)
O R903 1-216-295-91 SHORT 0 (103)
< NETWORK RESISTOR >
O RB120 1-234-030-11 RES, NETWORK (CHIP TYPE) 22X4
O RB121 1-234-030-11 RES, NETWORK (CHIP TYPE) 22X4
O RB122 1-234-030-11 RES, NETWORK (CHIP TYPE) 22X4
O RB123 1-233-955-11 RES, NETWORK (CHIP TYPE) 100X4
O RB124 1-233-967-11 RES, NETWORK (CHIP TYPE) 10KX4
O RB125 1-234-030-11 RES, NETWORK (CHIP TYPE) 22X4
O RB126 1-233-959-21 RES, NETWORK (CHIP TYPE) 470X4
O RB201 1-234-030-11 RES, NETWORK (CHIP TYPE) 22X4
(-11/-21/-31/-41/-51)
O RB202 1-234-030-11 RES, NETWORK (CHIP TYPE) 22X4
(-11/-21/-31/-41/-51)
O RB203 1-234-467-21 RES, NETWORK (CHIP TYPE) 82X4 (-41/-51)
O RB204 1-234-467-21 RES, NETWORK (CHIP TYPE) 82X4 (-41/-51)
O RB205 1-234-467-21 RES, NETWORK (CHIP TYPE) 82X4 (-41/-51)
O RB206 1-234-467-21 RES, NETWORK (CHIP TYPE) 82X4 (-41/-51)
O RB207 1-234-467-21 RES, NETWORK (CHIP TYPE) 82X4 (-41/-51)
O RB208 1-234-467-21 RES, NETWORK (CHIP TYPE) 82X4 (-41/-51)
O RB209 1-234-467-21 RES, NETWORK (CHIP TYPE) 82X4 (-41/-51)
O RB210 1-234-467-21 RES, NETWORK (CHIP TYPE) 82X4 (-41/-51)
O RB501 1-234-482-21 RES, NETWORK (CHIP TYPE) 75X4
O RB502 1-234-482-21 RES, NETWORK (CHIP TYPE) 75X4
< SWITCH >
O0 S001 1-762-745-22 SWITCH, PUSH (I/1/RESET)
O S301 1-771-764-11 SWITCH, PUSH (1 KEY) (CD DOOR
OPEN/CLOSE DET)
< VIBRATOR >
S X201 1-767-783-21 VIBRATOR, CRYSTAL (14.318182MHz) (NTSC)
S X201 1-767-940-22 VIBRATOR, CRYSTAL (17.73447MHz) (PAL)
*************************************************************
ACCESSORIES
************
<SCPH-100>
O0 AC 1-476-267-16 ADAPTOR, AC (SCPH-112)
O AV 1-792-028-11 CORD, CONNECTION (A/V CABLE)
O CONT 1-757-144-33 CORD, CONNECTION (ANALOG CONTROLLER)
O MANUAL 3-068-146-02 MANUAL, INSTRUCTION (JAPANESE)
<SCPH-101>
O0 AC 1-476-409-21 ADAPTOR, AC (SCPH-113)
O AV 1-792-028-11 CORD, CONNECTION (A/V CABLE)
O CONT 1-757-144-33 CORD, CONNECTION (ANALOG CONTROLLER)
O MANUAL 3-065-224-12 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
SPANISH)
<SCPH-102>
O0 AC 1-476-410-12 ADAPTOR, AC (SCPH-114) (102C)
O0 AC 1-476-411-11 ADAPTOR, AC (SCPH-115) (102B)
O0 AC 1-476-412-11 ADAPTOR, AC (SCPH-116) (102A)
O AV 1-792-028-11 CORD, CONNECTION (A/V CABLE)
O CONT 1-757-144-33 CORD, CONNECTION (ANALOG CONTROLLER)
O0 CONV 1-573-291-11 CONNECTOR, CONVERSION (102C)
O MANUAL 3-066-615-11 MANUAL, INSTRUCTION (ENGLISH) (102A)
O MANUAL 3-066-615-21 MANUAL, INSTRUCTION (ENGLISH) (102B)
O MANUAL 3-066-615-31 MANUAL, INSTRUCTION (FRENCH,SPANISH,
GERMAN,ITALIAN,DUTCH,PORTUGUESE)
(102C)
O MANUAL 3-066-615-53 MANUAL, INSTRUCTION (ENGLISH,RUSSIAN,
ARABIC) (102D)
O RF 1-476-040-31 ADAPTOR, RF (102B)
<SCPH-103>
O0 AC 1-476-410-12 ADAPTOR, AC (SCPH-114)
O0 AC 1-476-411-11 ADAPTOR, AC (SCPH-115)
O0 AC 1-476-587-11 ADAPTOR, AC (SCPH-117)
O0 AC 1-477-217-11 ADAPTOR, AC (SCPH-123D) (103D)
O AV 1-792-028-11 CORD, CONNECTION (A/V CABLE)
O CONT 1-757-144-33 CORD, CONNECTION (ANALOG CONTROLLER)
O MANUAL 3-066-615-42 MANUAL, INSTRUCTION (ENGLISH,
TRADITIONAL CHINESE,HUNGARIAN)
