Check the
connector of HDMI
cable with
HDMI jack
Check the 1.8V
and 3.3V at ICHD1
Pin 74 and 71
Check the Clock of
ICHD1 Pin 26, 27
Check PCMO_LRCK
and PCMO_SCK of ICHD1
Pin 11, 12
The SCL, SDA of
HDJACK-15, 16
normal?
Replace the ICHD1.
Correctthe HDMIcable Connector
Check the ICHD1 peripheral circuit.
Check the ICHD1 peripheral circuit.
Check IC101
Check the ICHD1 peripheralcircuit.
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
HDMI Video Out Error
