Line1 CVBS Video Input Error
Check JK801
(Video input signal)
No
Check VCC of AVIC1 and peripheral
parts of Clock oscillation
(Pin # 53, 54) of AVIC1
No
Yes
Yes
Check AVIC1
(Pin # 15)
Check VCC and peripheral parts of
AVIC1
No
Yes
Check AVIC1
(Pin # 75, 76, 79 -84)
Check peripheral parts of JK801
1. Check VCC of IC101 and peripheral
parts of Clock oscillation
(IC105 Pin # 1, 2, 14)
2. Refer to the “CVBS output error”
