Tuner video(analog) input Error
Is the 9pin of
E1 ok ?
Check the voltage and I2C line
of E1
No
Yes
Is the 14pin of
AVIC1 OK?
Check the short or open circuit
through TUNER_CVBS_IN signal line
Follow the instructions of
<CVBS OUTPUT ERROR>.
Yes
No
