Recommended setting 2
This setting is recommended for fine exposure adjustment using the ND filter and using AE when
appropriate.
Assignment table
Function assignment menu item Setting of the unit ILME-FR7 assignable button function assignment
OPERATION > WHITE > WB MODE MEM.A T/T –
CONFIG > RM SETUP > AE CONFIG2 ND FILTER –
CONFIG > SW ASSIGN > ASSIGN1 DISPLAY –
CONFIG > SW ASSIGN > ASSIGN2 ASSIGN 7 Video Signal Monitor
CONFIG > SW ASSIGN > ASSIGN3 ASSIGN 9 ND Filter Position
CONFIG > SW ASSIGN > ASSIGN4 ND FILTER –
CONFIG > SW ASSIGN > ASSIGN5 ASSIGN 6 Base ISO/Sensitivity
CONFIG > SW ASSIGN > ASSIGN6 AUDIO LVL –
CONFIG > SW ASSIGN > IRIS KNOB ND FILTER –
The orange labels indicate the buttons/
knobs used and their assigned
functions.
• All uppercase functions can be
assigned directly on this unit.
• Functions with mixed uppercase and
lowercase letters must be configured
on both this unit and the ILME-FR7.
