1-6-1. LAMP CONNECTOR AND T2 BOARD REMOVAL
1
Pull retaining clip outward to release and drop the high
voltage connector and the T2 Bracket.
2
Separate the HV Connector from the bracket
3
Remove 1 screw to release the T2 Board.
1
1
