Sony RM-YD010 - IRIS Adjustments

KF-42E200A/42E201A/50E200A/50E201A
KF-42E200A/42E201A/50E200A/50E201A
38
2-6. IRIS ADJUSTMENTS
Use the following instructions to adjust the IRIS after replacing
either of the following:
 Optical Block Assembly
 B Block Assembly
1. Access Service Adjustment Mode.
2. Press
2
until the IRIS_ADJ category displays.
3. Press
1
until the AUTO (7) item displays.
4. Press
3
to change the data value to 1.
5. Wait approximately 5 seconds until the data value is reset to 0.
6. To exit service mode, turn the power off by pressing
POWER
.
Wait 2 minutes before restarting the set to allow the fans to
completely shut down or the Service Menu will appear on the screen.
