6-13
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7073-516-A CD-185 BOARD, COMPLETE
**********************
(Ref.No.: 1,000 Series)
(IC451 is not included in this complete board)
< CAPACITOR >
C302 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C303 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C304 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C305 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C306 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C307 1-164-935-11 CERAMIC CHIP 470PF 10% 16V
C308 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C309 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C310 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C311 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C312 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C313 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C314 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C315 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C316 1-115-156-11 CERAMIC CHIP 1uF 10V
C317 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C318 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
C319 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C320 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
C321 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C323 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C451 1-113-990-11 TANTAL. CHIP 15uF 20% 16V
C452 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C453 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C455 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C456 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 16V
C458 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C650 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C651 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C652 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C653 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C654 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C655 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C660 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
C661 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
C666 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C667 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C668 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C669 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C670 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C671 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C672 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C677 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
C678 1-104-908-11 TANTAL. CHIP 47uF 20% 4V
< CONNECTOR >
CN451 1-784-994-21 CONNECTOR, BOARD TO BOARD 50P
CN452 1-766-354-21 CONNECTOR, FFC/FPC 24P
< DIODE >
D301 8-719-404-49 DIODE MA111-TX
< IC >
IC301 8-759-444-87 IC NJM324V(TE2)
IC302 8-759-351-46 IC MPC17A34RVMEL
IC451 A-7030-881-A CCD BLOCK ASSY (220 SERVICE)
(CCD IMAGER)(TRV9)
IC451 A-7030-885-A CCD BLOCK ASSY (221 SERVICE)
(CCD IMAGER)(TRV9E)
IC651 8-759-489-19 IC uPC6756GR-8JG-E2
< COIL >
L302 1-414-754-11 INDUCTOR 10uH
L303 1-414-754-11 INDUCTOR 10uH
L305 1-414-754-11 INDUCTOR 10uH
L451 1-414-757-11 INDUCTOR 100uH
L602 1-414-754-11 INDUCTOR 10uH
< TRANSISTOR >
Q301 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q302 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q303 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q304 8-729-037-53 TRANSISTOR 2SB1462J-QR(K8).SO
Q451 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
< RESISTOR >
R301 1-218-989-11 RES,CHIP 1M 5% 1/16W
R303 1-218-961-11 RES,CHIP 4.7K 5% 1/16W
R304 1-218-975-11 RES,CHIP 68K 5% 1/16W
R305 1-218-961-11 RES,CHIP 4.7K 5% 1/16W
R307 1-218-975-11 RES,CHIP 68K 5% 1/16W
R308 1-216-295-91 SHORT 0
R310 1-218-953-11 RES,CHIP 1K 5% 1/16W
R311 1-218-985-11 RES,CHIP 470K 5% 1/16W
R312 1-218-981-11 RES,CHIP 220K 5% 1/16W
R313 1-218-985-11 RES,CHIP 470K 5% 1/16W
R314 1-218-985-11 RES,CHIP 470K 5% 1/16W
R315 1-218-965-11 RES,CHIP 10K 5% 1/16W
R316 1-218-967-11 RES,CHIP 15K 5% 1/16W
R317 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R318 1-218-989-11 RES,CHIP 1M 5% 1/16W
R319 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R320 1-218-973-11 RES,CHIP 47K 5% 1/16W
R321 1-218-969-11 RES,CHIP 22K 5% 1/16W
R322 1-218-969-11 RES,CHIP 22K 5% 1/16W
R323 1-218-947-11 RES,CHIP 330 5% 1/16W
R324 1-218-953-11 RES,CHIP 1K 5% 1/16W
R325 1-218-953-11 RES,CHIP 1K 5% 1/16W
R326 1-218-953-11 RES,CHIP 1K 5% 1/16W
R327 1-218-965-11 RES,CHIP 10K 5% 1/16W
R328 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R329 1-218-973-11 RES,CHIP 47K 5% 1/16W
R330 1-216-158-00 RES,CHIP 22 5% 1/8W
R452 1-218-957-11 RES,CHIP 2.2K 5% 1/16W
R454 1-218-990-11 SHORT 0
R650 1-218-969-11 RES,CHIP 22K 5% 1/16W
R651 1-218-969-11 RES,CHIP 22K 5% 1/16W
R652 1-218-969-11 RES,CHIP 22K 5% 1/16W
R653 1-218-969-11 RES,CHIP 22K 5% 1/16W
R654 1-216-295-91 SHORT 0
R655 1-216-295-91 SHORT 0
CD-185
Be sure to read “Note on the CCD imager replacement” on
page 4-5 when changing the CCD Imager.
To Next Page
