6-34E
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R9622 1-218-937-11 RES,CHIP 47 5% 1/16W
R9623 1-218-937-11 RES,CHIP 47 5% 1/16W
< VIBRATOR >
X9001 1-579-466-11 VIBRATOR, CRYSTAL 3.579545MHz (TRV9)
X9001 1-579-661-21 OSCILLATOR, CRYSTAL 4.43619MHz (TRV9E)
************************************************************
MISCELLANEOUS
*************
5 1-669-511-11 FP-654 FLEXIBLE BOARD
6 1-475-707-11 SWITCH BLOCK, CONTROL (MF4580)
7 1-694-411-11 TERMINAL BOARD, BATTERY
54 1-475-705-11 SWITCH BLOCK, CONTROL (CF4580)
59,210 1-958-570-11 HARNESS (BT-55)
61 1-958-571-11 HARNESS (SP-151)
110 1-669-512-21 FP-655 FLEXIBLE BOARD
112 1-669-513-11 FP-656 FLEXIBLE BOARD
152 1-475-708-21 SWITCH BLOCK, CONTROL (BV4580)
203 1-669-509-21 FP-650 FLEXIBLE BOARD
205 1-669-511-11 FP-654 FLEXIBLE BOARD
210 1-958-570-11 HARNESS (BT-55)
261 1-475-706-21 SWITCH BLOCK, CONTROL (PS4580)
(TRV9/TRV9E:EXCEPT AEP,UK)
261 1-475-706-31 SWITCH BLOCK, CONTROL (PS4580)
(TRV9E:AEP,UK)
262 1-475-704-21 SWITCH BLOCK, CONTROL (FK4580)
(TRV9/TRV9E:EXCEPT AEP,UK)
262 1-475-704-31 SWITCH BLOCK, CONTROL (FK4580)
(TRV9E:AEP,UK)
265 1-669-510-11 FP-653 FLEXIBLE BOARD
266 1-774-867-21 CONNECTOR,EXTERNAL(HOT SHOE)8P
269 1-669-507-21 FP-648 FLEXIBLE BOARD
(TRV9/TRV9E:EXCEPT AEP,UK)
301 1-758-154-11 LENS, ZOOM (VCL-5115VA)
304 1-758-155-21 FILTER BLOCK, OPTICAL
812 1-657-785-11 FP-248 FLEXIBLE BOARD
IC451 A-7030-881-A CCD BLOCK ASSY (TRV9)
IC451 A-7030-885-A CCD BLOCK ASSY (TRV9E)
LCD901 1-803-033-21 INDICATOR MODULE, LIQUID CRYSTAL
LCD902 8-753-023-37 LCX024AK-4
M901 A-7044-024-A DRUM ASSY (DEH-07D-R)
M902 X-3948-346-1 MOTOR ASSY, L (LOADING)
M903 8-835-606-01 MOTOR, DC SCD15A/C-NP (CAPSTAN)
M904 3-709-400-01 MOTOR, FOCUS
M905 3-709-399-01 MOTOR, ZOOM
MIC901 1-542-350-11 MICROPHONE UNIT
! ND901 1-517-754-11 TUBE, FLUORESCENT,COLD CATHODE
SP901 1-505-619-11 SPEAKER (2.0 CM)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-141-21 REMOTE COMMANDER RMT-808E
(TRV9/TRV9E:EXCEPT AEP,UK)
1-475-141-31 REMOTE COMMANDER RMT-809E
(TRV9E:AEP,UK)
1-569-008-21 ADAPTOR, CONVERSION 2P (E,HK,JE)
1-573-291-11 CONNECTOR, CONVERSION 21P
(TRV9E:AEP,UK)
1-765-080-11 AV CONNECTING CABLE 1.5m
(TRV9/TRV9E:EXCEPT AEP,UK)
1-777-433-21 CORD, CONNECTION (TRV9E:AEP,UK)
3-862-548-11 MANUAL, INSTRUCTION (ENGLISH)
(TRV9:US,CND)
3-862-548-21 MANUAL, INSTRUCTION (FRENCH)
(TRV9:CND)
3-862-548-31 MANUAL, INSTRUCTION (ENGLISH)
(TRV9:E,HK,JE)
3-862-548-41 MANUAL, INSTRUCTION
(SPANISH, PORTUGUESE) (TRV9:E,HK,JE)
3-862-548-51 MANUAL, INSTRUCTION (CHINESE)
(TRV9:E,HK)
3-862-548-61 MANUAL, INSTRUCTION (KOREAN) (TRV9:JE)
3-862-549-11 MANUAL, INSTRUCTION (ENGLISH, RUSSIAN)
(TRV9E:AEP,UK)
3-862-549-21 MANUAL, INSTRUCTION (GERMAN, ITALIAN)
(TRV9E:AEP)
3-862-549-31 MANUAL, INSTRUCTION
(SPANISH, PORTUGUESE) (TRV9E:AEP)
3-862-549-41 MANUAL, INSTRUCTION ((FRENCH, GERMAN)
(TRV9E:AEP)
3-862-549-51 MANUAL, INSTRUCTION (ENGLISH, RUSSIAN)
(TRV9E:EXCEPT AEP,UK)
3-862-549-61 MANUAL, INSTRUCTION (FRENCH, GERMAN)
(TRV9E:CN,E,HK,JE)
3-862-549-71 MANUAL, INSTRUCTION (ARABIC, PERSIAN)
(TRV9E:CN,E)
3-862-549-81 MANUAL, INSTRUCTION (CHINESE)
(TRV9E:CN,E,JE)
3-862-549-91 MANUAL, INSTRUCTION (CHINESE)
(TRV9E:HK)
3-948-162-02 EYE CUP
3-987-015-01 BELT (S), SHOULDER
X-3948-885-1 ADAPTOR ASSY, F
** A-7009-233-A AC-V316 AC ADAPTOR (US,CND)
** A-7009-234-C AC-V316 AC ADAPTOR (E,JE)
** A-7009-237-B AC-V316 AC ADAPTOR (AUS)
** A-7009-238-B AC-V316 AC ADAPTOR (HK)
** A-7009-749-A AC-V326 AC ADAPTOR (AEP)
** A-7009-750-A AC-V326 AC ADAPTOR (UK)
** A-7029-069-A AC-V326 AC ADAPTOR (CN)
** NP-F330 BATTERY PACK
Note:
** MARK PARTS IS AVAILABLE AS AN OPTIONAL ACCESSORY
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
VI-148
