RDR-HX510
4-44-3
WAVEFORMS
AV-089/ER-036/RD-053
(For schematic diagrams)
• All capacitors are in µF unless otherwise noted. pF : µµF.
50V or less are not indicated except for electrolytics and
tantalums.
• All resistors are in ohms, 1/4 W (Chip resistors : 1 /10 W) un-less
otherwise specified.
kΩ=1000Ω, MΩ=1000kΩ.
• Caution when replacing chip parts.
New parts must be attached after removal of chip.
Be careful not to heat the minus side of tantalum capacitor, be-
cause it is damaged by the heat.
• All variable and adjustable resistors have characteristic curve B,
unless otherwise noted.
• 2 : non flammable resistor
• 5 : fusible resistor
• C : panel designation
• f : internal component.
• C : adjustment for repair.
• U : B+ Line
• V : B– Line
• Circled numbers refer to waveforms.
• Voltages are dc between measurement point.
• Readings are taken with a color-bar signals on DVD reference
disc.
• Readings are taken with a digital multimeter (DC 10MW).
• Voltage variations may be noted due to normal production toler-
ances.
THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS
(In addition to this, the necessary note is printed in each block)
When indicating parts by reference number, please include
the board name.
4-2. SCHEMATIC DIAGRAMS WAVEFORMS
Note : The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
AV-089 BOARD
30.5 us
1.6 Vp-p
1 IC604 0
100 ns
4.2 Vp-p
2 IC604 qs
ER-036 BOARD
H
1.9 Vp-p
1 IC103 ql
H
0.8 Vp-p
2 IC104 qg
H
1.6 Vp-p
3 IC104 ql
54.3 ns
3.7 Vp-p
4 IC301 6
RD-053
BOARD
30 us
1.7 Vp-p
1
IC104
@
(JL128)
37 us
4.4 Vp-p
2
IC1001 4678
37 us
3.8 Vp-p
3
IC1001 qs
40.8 us
4.4 Vp-p
4
IC1001 qfqg
40.8 ns
5.1 Vp-p
5
IC1001 qkql
81.3 ns
4.6 Vp-p
6
IC1001 w;
A2
To Next Page
