47
GB
and [BT] - [STANDBY] are set to [ON])
* The system will automatically enter
Power saving mode when there is no
HDMI connection and no
BLUETOOTH pairing history.
Dimensions* (approx.) (w/h/d)
980 mm × 64 mm × 108 mm
* Not including projection portion
Mass (approx.)
3.5 kg
POWER OUTPUT (reference)
100 W (at 4 ohms, 100 Hz)
Speaker system
Subwoofer speaker system, Bass
reflex
Speaker
160 mm cone type
Power requirements
220 V - 240 V AC, 50 Hz/60 Hz
Power consumption
On: 20 W
Standby mode: 0.5 W or less
Dimensions (approx.) (w/h/d)
192 mm × 387 mm × 406 mm
* Not including projection portion
Mass (approx.)
7.5 kg
Frequency band
2.4 GHz (2.404 GHz - 2.476 GHz)
Maximum output power
< 11 dBm
Modulation method
GFSK
Design and specifications are subject to
change without notice.
Subwoofer (SA-WG700)
Wireless Transmitter/
Receiver Section
To Next Page
