Supported HDMI Video Formats
Video formats supported by this system are as follows.
: Compatible with 3D signal in Side-by-Side (Half) format
: Compatible with 3D signal in Frame packing and Over-Under (Top-and-Bottom) format
1)
Use a Premium High Speed HDMI Cable with Ethernet that supports 18 Gbps.
2)
Use a Premium High Speed HDMI Cable with Ethernet or Sony High Speed HDMI Cable
with Ethernet with the Cable Type Logo.
• Use an HDMI-authorized cable.
• We do not recommend using an HDMI-DVI conversion cable.
• Audio signals (sampling frequency, bit length, etc.) transmitted from an HDMI jack
may be suppressed by the connected device.
• Sound may be interrupted when the sampling frequency or the number of channels
of audio output signals from the playback device is switched.
• When the TV input is selected, video signals via the HDMI IN jack are output from
the HDMI OUT (TV eARC/ARC) jack.
• This system supports “TRILUMINOS.”
Resolution
Frame Rate 3D Color Space Color Depth
[HDMI] - [FORMAT]
setting
4K
4096 × 2160p
3840 × 2160p
50/59.94/60 Hz
–
RGB 4:4:4
YCbCr 4:4:4
8 bit
[ENHANCED]
1)
–
YCbCr 4:2:2 8/10/12 bit
–
YCbCr 4:2:0 10/12 bit
23.98/24/25/29.97/30 Hz
–
RGB 4:4:4
YCbCr 4:4:4
10/12 bit
4K
4096 × 2160p
3840 × 2160p
50/59.94/60 Hz
–
YCbCr 4:2:0 8 bit
[STANDARD]
2)
23.98/24/25/29.97/30 Hz
–
RGB 4:4:4
YCbCr 4:4:4
8 bit
–
YCbCr 4:2:2 8/10/12 bit
1920 × 1080p
25/29.97/30/50/
59.94/60 Hz
–
RGB 4:4:4
YCbCr 4:4:4
YCbCr 4:2:2
8/10/12 bit
23.98/24 Hz
1920 × 1080i 50/59.94/60 Hz
1280 × 720p
50/59.94/60 Hz
23.98/24/29.97/30 Hz
–
720 × 480p 59.94/60 Hz
–
720 × 576p 50 Hz
–
640 × 480p 59.94/60 Hz
–
RGB 4:4:4
Notes on HDMI Jack and HDMI Connections
