— 3 —
SAL28F28 (2.8/28) (28mm F2.8)
TABLE OF CONTENTS
Section Title Page
1. SERVICE NOTE
1-1. Chemicals ······································································· 1-1
1-2. Exterior Parts ·································································· 1-1
1-3. Unleaded Solder ····························································· 1-1
1-4. Safety Check-out ···························································· 1-2
1-5. Troubleshooting ····························································· 1-3
2. DISASSEMBLY
2-1. Disassembly ··································································· 2-2
3. REPAIR PARTS LIST
3-1. Exploded Views ······························································3-1
3-2. Supplied Accessories ······················································ 3-4
4. ADJUSTMENTS
4-1. Preparations ···································································· 4-1
4-2. Aperture Diameter Check/Adjustment ··························· 4-4
4-3. Projective Resolving Power Check ································4-9
4-4. Flange Back (f’F) Check/Adjustment ·························· 4-12
4-5. Lens ROM Check ························································· 4-16
4-6. Error Code List ····························································· 4-17
