4
Unpacking
Check that you received the following items with your
speaker system:
• External center speaker SS-CN15VA (1)
• Rear speaker SS-SR171 (2)
• Front L/R speaker connecting cord, 3.5 m (1)
• Center speaker connecting cord, 2.5 m (1)
• Rear speaker connecting cord, 10 m (2)
• Audio connecting cord, 1.5 m (1)
• Remote commander (remote) RM-J59 (1)
• Sony size-AA (R6) batteries (2)
• Speaker bases (2)
• Wood screws (8)
• Foot pads (4)
Inserting batteries into the remote
Insert two size-AA (R6) batteries with the terminals
matched to the + and – on the battery compartment.
When using the remote, point it at the remote sensor g
on the front speaker (left).
]
}
]
}
z When to replace batteries
Under normal use, the batteries should last for about 6
months. When the remote no longer operates the
speakers, replace both batteries with new ones.
Notes
• Do not leave the remote in an extremely hot or humid
place.
• Do not use a new battery with an old one.
• Do not expose the remote sensor to direct sunlight or
lighting apparatuses. Doing so may cause a malfunction.
• If you do not use the remote for an extended period of
time, remove the batteries to avoid possible damage from
battery leakage and corrosion.
Installing the speaker bases
Be sure to install the supplied speaker bases before you
use the speakers.
1 Use a screw driver to fasten the bases to the
bottom of the speakers with the supplied wood
screws.
2 Make sure the bases are securely attached and
stand the speaker upright.
Getting Started
Attaching the supplied foot pads to the
external center speaker
To place the external center speaker on your TV set,
attach the supplied foot pads to the bottom of the
speaker, one in each of the four corners. Make sure
that the speaker stands flat on top of the TV.
Do not place the speaker on top of a TV set which is smaller
than the speaker.
Foot pads
