Sony SDM-S91 - Table of Contents

SDM-S91(E) 6
1. DISASSEMBLY
1-1. Back Cabinet and TFT Panel Removal ................ 1-1
1-2. Keyboard Mount Removal ................................... 1-2
1-3. Inverter Mount Removal ...................................... 1-3
1-4. I/F Board Removal ............................................... 1-4
1-5. TFT Panel Removal .............................................. 1-5
2. DIAGRAMS
2-1. Circuit Boards Location ........................................ 2-1
3. EXPLODED VIEWS
3-1. Chassis ................................................................. 3-2
3-2. Packing Materials ................................................. 3-3
TABLE OF CONTENTS
Section Title Page Section Title Page
