Sony SEQ-555ES - Page 45

ELECTRICAL PARTS
Ref.No. Part No.
$801 1-553-164-00
$901 A 1-552-535-00
T501 A. 1-447-881-11
T501 A.1-447-879-11
T801 A.1-447-882-11
T801 A.1-447-880-11
TB301 *1-535-116-00
TB302 *1-535-117-00
TB501 *1-535-115-00
TB502 = 1-535-136-00
X§01 = 1-527-532-00
X502 1-567-160-00
Description
SWITCH, SLIDE
(AEP,E)..«SWITCH, POWER & VOLTAGE CHANGE
(AEP ,E)....+.+. TRANSFORMER, POWER
(US,Canadian)}... TRANSFORMER, POWER
(AEP ,E).e++eee2-TRANSFORMER, POWER
(US, Canadian)... TRANSFORMER, POWER
TERMINAL
TERMINAL
TERMINAL
BASE POST 14MM (10MM PITCH) 3P
OSCILLATOR, CERAMIC
OSCILLATOR, CERAMIC
NOTE:
The mechanical parts with no reference
number in the exploded views are not
supplied.
* Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be antici-
Pated when ordering these items.
‘ If there are two or more same circuitsin a
set such as a stereophonic machine, only
typical circuit parts may be indicated and.
capacitors and resistors in other same
circuits may be omitted.
CA
co
PACITORS:
All capacitors are in uf. Common ca-
pacitors are omitted. Refer to the
following lists for their part numbers.
MF: pF, PF:unF.
ILS
* MMH : mH, UH : pH
SEMICONDUCTORS
In each case, U : np, for example:
UA+++: HA+-+, UPA---: uPA---, UPC---: pPC,
UPD---: uPD---
—63—
SEQ-555ES
The components identified
by shading and mark A\are
critical for safety.
Replace only with part
number specified.
Les composants identifiés par
une trame et une marque /\sont
critiques pour la securite.
Ne les remplacer que par
une piece portant le numéro
ei fig
