Sony SLT-A65 - Page 19

SLT-A65/A65K/A65L/A65M/A65V/A65VK/A65VL/A65VM/A65VX/A65VY/A65X/A65Y_L2
2-3
2-1. EXPLODED VIEWS
2-1-1. OVERALL SECTION-1
DISASSEMBLY
1. Remove in numerical order (1to 4) in the left figure.
Back View
#112
Ref. No. Part No. Description
Ref. No. Part No. Description
#11
2
#12
#12
#12
#2
#2
1
1
AM-026
2 2
Overall Section-2
(See page 2-6)
3 Rear Cover Section
(See page 2-4)
4
1 4-293-607-01 VM EYE CUP (868)
∗ 2 4-154-680-01 CV DIOPTER ADJUST DIAL (857)
#2 2-635-562-31 SCREW (M1.7)
#12 3-080-204-21 SCREW, TAPPING, P2
#112 2-178-410-11 TITE (UB TITE) 1.4
DISCHARGING OF THE CHARGING CAPACITOR
ストロボ用充電コンデンサの放電
4
2 #112 X 1
Back View Left ViewRight ViewBottom View
#12
#2
#12
#2
3 #12 X 2 → #2 X 4 → #12 X 2
Screw
#2: M1.7 X 4.0
(Black)
2-635-562-31
4.0
1.7
#12: M1.7 X 5.0 (Tapping)
(Black)
3-080-204-21
1.7
5.0
#112: M1.4 X 5.0
(Black)
2-178-410-11
5.0
1.4
