Sony SLTA77 - Repair Parts List; Electrical Parts List

SLT-A77/A77Q/A77V/A77VK/A77VQ_L3
2-1
2. REPAIR PARTS LIST
A-1799-042-A ALX-8700
(Not supplied) AF-138 FLEXIBLE BOARD, COMPLETE
******************************
(All mounted parts and AF-138 FLEXIBLE COMPLETE BOARD are not supplied, but
they are included in ALX-8700.)
A-1837-337-A AF DRIVING UNIT
(Not supplied) AFP-007 FLEXIBLE BOARD, COMPLETE
*******************************
(All mounted parts and AFP-007 FLEXIBLE COMPLETE BOARD are not supplied, but
they are included in AF DRIVING UNIT.)
A-1848-975-A AM-027 BOARD, COMPLETE (SERVICE)
*******************************
(IC1001 and IC2206 are not supplied, but they are included in AM-027 COMPLETE
BOARD (SERVICE).)
< BATTERY HOLDER >
 BH3101 1-251-928-21 HOLDER, BATTERY
< BATTERY >
 BT3101 1-756-134-15 BATTERY, LITHIUM (SECONDARY)
< CAPACITOR >
C0002 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C0004 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0005 1-100-672-11 CERAMIC CHIP 10uF 20% 16V
C0007 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C0010 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0011 1-114-354-11 CERAMIC CHIP 0.1uF 10% 16V
C0012 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C0017 1-114-354-11 CERAMIC CHIP 0.1uF 10% 16V
C0018 1-114-354-11 CERAMIC CHIP 0.1uF 10% 16V
C0020 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C0021 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C0025 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C0026 1-112-717-91 CERAMIC CHIP 1uF 10% 6.3V
C0027 1-100-696-91 CERAMIC CHIP 1uF 10% 6.3V
C0028 1-114-238-91 CERAMIC CHIP 22uF 20% 10V
C0029 1-114-238-91 CERAMIC CHIP 22uF 20% 10V
C0030 1-114-238-91 CERAMIC CHIP 22uF 20% 10V
C0031 1-114-238-91 CERAMIC CHIP 22uF 20% 10V
C0032 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C0033 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C0034 1-100-252-11 CERAMIC CHIP 0.1uF 10% 6.3V
C0035 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C0036 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C0037 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C0038 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C0041 1-100-696-91 CERAMIC CHIP 1uF 10% 6.3V
C0042 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
C0043 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C0044 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
C0045 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
C0047 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
C0049 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C0050 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
Ref. No. Part No. Description
C0051 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C0053 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C0062 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C0064 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C0065 1-164-864-11 CERAMIC CHIP 39PF 5% 50V
C0501 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1011 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1012 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1013 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1014 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1016 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1017 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1018 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1019 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1021 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1022 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1023 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1024 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1025 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1026 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1027 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1028 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1029 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1033 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1034 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1035 1-100-696-91 CERAMIC CHIP 1uF 10% 6.3V
C1037 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1039 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1040 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1041 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1042 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1043 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1045 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1046 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C1111 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1112 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C1113 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1114 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1115 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1116 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1117 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1118 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1120 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1121 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1122 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1127 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1128 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1129 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1130 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1131 1-164-849-11 CERAMIC CHIP 9PF 0.5PF 50V
C1132 1-164-849-11 CERAMIC CHIP 9PF 0.5PF 50V
C1135 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1136 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1137 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1139 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1141 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1143 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1145 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
Ref. No. Part No. Description
2-2. ELECTRICAL PARTS LIST
AF-138 AFP-007 AM-027
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some dif-
ferences from the original one.
• Items marked “*” are not stocked since they are seldom required
for routine service. Some delay should be anticipated when
ordering these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may be
different from the parts specified in the diagrams or the com-
ponents used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , μPC... , μPC... ,
uPD..., μPD...
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は,補修用部品であるため,回路図
及びセットに付いている部品と異なる場合があります。
• -XX,-Xは標準化部品のため,セットに付いている部品と異な
る場合があります。
•
*
印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
 金 被：金属被膜抵抗。
 サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれ
μA...,μPA...,μPB...,μPC...,μPD...を示します。
The components identified by mark 0 or
dotted line with mark are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
図面番号で部品を指定するときは基板名
又はブロックを併せて指定してください。
お願い
0
印の部品，または
0
印付の点線で囲ま
れた部品は，安全性を維持するために，
重要な部品です。
従って交換時は，必ず指定の部品を使用
してください。
When indicating parts by reference
number, please include the board name.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
Note 1: Be sure to read “Precautions for Replacement of Imager”
on page 6-1.
Note 1:
イメージャの交換時は6-1ページの“イメージャ交換時の
注意”を必ずお読みください。
Note 2: Replace the battery holder (BH3101) together when replac-
ing the lithium secondary battery (BT3101) on the AM-027
board. (The battery holder removed once cannot be used
again.) When mounting these parts, mount new battery
holder first and attach new lithium storage battery next.
Note 2:
AM-027基板のリチウム蓄電池（BT3101） を交換する場
合はバッテリホルダ（BH3101）も同時に新品に交換して
ください。（一度使用したバッテリホルダは再使用でき
ません。）部品取り付けの際は、先にバッテリホルダを
取り付けてからリチウム蓄電池を装着してください。
