Sony SLTA77 - Rm-100 Flexible Board; Ap-037 Flexible Board

SLT-A77/A77Q/A77V/A77VK/A77VQ_L3
6-41
: Uses unleaded solder.
All mounted parts (except SP901) are not supplied, but they are
included in RM-100 FLEXIBLE BOARD, COMPLETE.
Note 2:
REMOTE
LND7407
LND7406
LN7401
114
CN7401
110
1-884-791- 21
RM-100 FLEXIBLE BOARD
LND7404 LND7403 LND7402
08
Note 1: SP901 is not included in RM-100 FLEXIBLE COMPLETE BOARD.
SP901
(SPEAKER)
RED
BLK
XX
mkOR C
AP-037
1
1-885-045- 11
M902
(APERTURE MOTOR)
RV8201
ROTARY POSITION
SENSOR
()
AP-037 FLEXIBLE BOARD
Note: All mounted parts and AF-037 FLEXIBLE COMPLETE BOARD are
not supplied, but they are included in AP APERTURE UNIT (SERVICE).
LN8212
LN8211
LN8206 LN8207 LN8209 LN8210 LN8208
LN8205 LN8204 LN8202 LN8201 LN8203
PH8201
3
3
6
4
1
1
5
M
