7-12
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Note :
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
R561 1-216-037-00 METAL CHIP 330 5% 1/10W
R562 1-249-407-11 CARBON 150 5% 1/4W F
R563 1-249-408-11 CARBON 180 5% 1/4W F
R564 1-216-021-00 METAL CHIP 68 5% 1/10W
R565 1-216-022-00 METAL CHIP 75 5% 1/10W
! R600 1-219-779-51 CARBON 6.8M 10% 1/2W
R601 1-249-441-11 CARBON 100K 5% 1/4W
R602 1-249-441-11 CARBON 100K 5% 1/4W
R603 1-249-429-11 CARBON 10K 5% 1/4W
R604 1-216-451-11 METAL OXIDE 120 5% 2W F
R605 1-215-416-00 METAL 620 1% 1/4W
R606 1-249-402-11 CARBON 56 5% 1/4W F
R607 1-215-927-41 METAL OXIDE 47K 5% 3W
R608 1-249-401-11 CARBON 47 5% 1/4W F
R609 1-249-406-11 CARBON 120 5% 1/4W F
R610 1-208-789-11 RES,CHIP 2K 0.50% 1/10W
R611 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R612 1-219-786-81 FUSIBLE 22 5% 1/4W
R613 1-260-091-11 CARBON 220 5% 1/2W
! R614 1-240-306-81 FUSIBLE 15 5% 1/4W
R615 1-249-417-11 CARBON 1K 5% 1/4W F
R616 1-247-815-91 CARBON 220 5% 1/4W
R617 1-249-417-11 CARBON 1K 5% 1/4W F
R618 1-260-091-11 CARBON 220 5% 1/2W
R619 1-249-413-11 CARBON 470 5% 1/4W F
R620 1-249-413-11 CARBON 470 5% 1/4W F
R623 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R624 1-216-430-11 METAL OXIDE 390 5% 1W F
R625 1-249-429-11 CARBON 10K 5% 1/4W
R630 1-216-049-00 METAL CHIP 1K 5% 1/10W
R633 1-216-295-00 METAL CHIP 0 5% 1/10W
R637 1-247-815-91 CARBON 220 5% 1/4W
R641 1-219-123-11 FUSIBLE 0.47 5% 1/4W F
! R642 1-216-374-41 METAL OXIDE 2.7 5% 2W
R643 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R701 1-216-049-00 METAL CHIP 1K 5% 1/10W
R702 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R703 1-216-039-00 METAL CHIP 390 5% 1/10W
R704 1-216-043-91 RES,CHIP 560 5% 1/10W
! R705 1-240-307-81 FUSIBLE 560 5% 1/4W
R706 1-216-113-00 METAL CHIP 470K 5% 1/10W
R707 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R709 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R710 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R711 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R712 1-216-295-00 METAL CHIP 0 5% 1/10W
R713 1-216-295-00 METAL CHIP 0 5% 1/10W
R731 1-216-049-00 METAL CHIP 1K 5% 1/10W
R732 1-216-049-00 METAL CHIP 1K 5% 1/10W
R733 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R734 1-216-049-00 METAL CHIP 1K 5% 1/10W
R735 1-216-049-00 METAL CHIP 1K 5% 1/10W
R736 1-216-295-00 METAL CHIP 0 5% 1/10W
R737 1-216-081-00 METAL CHIP 22K 5% 1/10W
R738 1-216-081-00 METAL CHIP 22K 5% 1/10W
R981 1-216-295-00 METAL CHIP 0 5% 1/10W
< SWITCH >
S101 1-762-108-11 SWITCH, PUSH (1 KEY)
S102 1-771-155-11 SWITCH, ROTARY (MECHANICAL MODE)
S407 1-771-574-21 SWITCH, TACTILE (EASY SET UP)
S409 1-771-574-21 SWITCH, TACTILE (TRACKING/CHANNNEL–)
S411 1-771-574-21 SWITCH, TACTILE (TRACKING/CHANNNEL+)
S701 1-571-588-11 SWITCH, SLIDE (RF UNIT CH3/CH4)
< TRANSFORMER >
T301 1-433-479-11 TRANSFORMER, BIAS OSCILLATION
! T600 1-433-568-11 TRANSFORMER, CONVERTER (RCC)
< TUNER >
TU701 8-598-473-00 TUNER, FSS BTF-MA431
< VARISTOR >
! VDR600 1-801-445-31 VARISTOR TNR10V241K660
< VIBRATOR >
X160 1-767-857-11 VIBRATOR, CRYSTAL (14.31818MHz)
X161 1-579-463-11 VIBRATOR, CRYSTAL (32.768kHz)
X201 1-577-380-11 VIBRATOR, CRYSTAL (3.579545MHz)
************************************************************
* A-6791-803-A MF-316 BOARD, COMPLETE
***********************
(Ref.No.:2,000 Series)
< CAPACITOR >
C461 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C493 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C495 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C496 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN461 1-568-954-11 PIN, CONNECTOR (STRAIGHT) 5P
CN491 1-506-484-11 PIN, CONNECTOR 5P
< JACK >
CNJ491 1-766-861-11 JACK, PIN (3P) (LINE-2 IN)
< DIODE >
D461 8-719-056-07 DIODE SLR-342MC3F (POWER)
D491 8-719-067-40 DIODE STZ6.8N-T146
D492 8-719-067-40 DIODE STZ6.8N-T146
D493 8-719-422-37 DIODE MA8051
D494 8-719-067-40 DIODE STZ6.8N-T146
< IC >
IC461 8-749-011-05 IC GP1U28X (REMOTE CONTROL)
< TRANSISTOR >
Q461 8-729-421-22 TRANSISTOR UN2211
MA-341 MF-316
