7-13E
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
MF-316
< RESISTOR >
R461 1-216-013-00 METAL CHIP 33 5% 1/10W
R462 1-216-029-00 METAL CHIP 150 5% 1/10W
R463 1-216-089-00 METAL CHIP 47K 5% 1/10W
R491 1-216-295-00 METAL CHIP 0 5% 1/10W
R492 1-216-295-00 METAL CHIP 0 5% 1/10W
R493 1-216-022-00 METAL CHIP 75 5% 1/10W
< SWITCH >
S461 1-762-196-21 SWITCH, TACT (POWER)
************************************************************
MISCELLANEOUS
**************
! 16 1-790-293-31 CORD, POWER
18 1-779-725-11 CONNECTOR, BOARD TO BOARD 5P
704 1-500-144-11 HEAD, FE
776 8-839-057-51 DRUM ASSY, DZH-0A7A/Z-NP
832 1-766-723-21 CONNECTOR, BOARD TO BOARD 3P
M902 1-698-971-11 MOTOR, DC
M903 X-3947-577-1 MOTOR ASSY, CAM
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-575-334-11 CORD, CONNECTION
1-696-592-11 CORD, CONNECTION (NTSC) (FOR RF)1.5m
1-418-153-11 COMMANDER, STANDARD (RMT-V266)
3-709-432-01 COVER, REMOTE CONTROL BATTERY
3-865-083-11 MANUAL, INSTRUCTION (ENGLISH)
3-865-083-21 MANUAL, INSTRUCTION
(FRENCH/CHINESE)(722/779:CND)
* 3-987-421-01 CUSHION
**************
HARDWARE LIST
**************
#1 7-685-648-79 SCREW +BVTP 3 × 12 TYPE2 IT-3
#2 7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 IT-3
#701 7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 IT-3
#702 7-682-147-01 SCREW +P 3 × 6
#703 7-685-133-19 SCREW (DIA. 2.6) (IT3B)
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
