97
Additional Information
Specifications
Canadian model:
(8 ohms at 1 kHz, THD 0.8%)
Front 70 W/ch
Center 70 W
(only in the PRO LOGIC
and THEATER mode)
Rear 70 W
Dynamic power output
8 ohms: 95 W + 95 W
4 ohms: 130 W + 130 W
Frequency response
CD, TAPE/MD, VIDEO 1, VIDEO 2,
TV, and LINE : 10 Hz - 50 kHz ± 1 dB
Inputs
CD
Sensitivity 220 mV
Impedance 50 kilohms
S/N 82 dB,
(Weighting
network, input
level)
TAPE/MD, VIDEO1, VIDEO2, TV,
and LINE
Sensitivity 180 mV
Impedance 50 kilohms
S/N 82 dB,
(Weighting
network, input
level)
Outputs
TAPE/MD REC OUT
Voltage 180 mV,
Impedance 10 kilohms
MIX AUDIO OUT
Voltage : 2 V
Impedance : 10 kilohms
PHONES
Accepts low and high impedance
headphones
Muting
–20 dB
BASS BOOST
+10 dB at 70 Hz
TONE
±8 dB at 100 Hz and 10 kHz
FM tuner section
Tuning range
87.5 - 108.0 MHz
Antenna terminal
75 ohms, unbalanced
AM tuner section
Tuning range
With 10 kHz interval**:
530 - 1710 kHz
With 9 kHz interval:
531 - 1710 kHz
Antenna Loop antenna
**You can change the AM tuning interval to
9 kHz. After turning in any AM station,
turn off the power, hold down the FM/AM
button and press the POWER switch. To
reset the interval to 10 kHz, repeat the
prodecure.
General
Power requirements
120 V AC, 60 Hz
Power consumption
190 W
AC outlet
Switched 120 W / 1A MAX
Operating temperature
5°C to 40°C
Storage temperature
–20°C to 60°C
Dimensions
Approx. 430 × 157 × 430 mm
(17 × 6
1
/
4
× 17 inches) (w/h/d)
including projecting parts and
controls
Mass
USA model:
Approx. 13.3 kg (29 lb 6 oz)
Canadian model:
Approx. 13.0 kg (28 lb 11 oz)
Supplied accessories
Remote commander (1)
Size AA (R6) batteries (2)
75-ohm coaxial cable with F-type
connectors (1)
Video cable (1 phono to 1 phono) (1)
AM loop antenna (1)
FM wire antenna (1)
Design and specifications are subject to
change without notice.
System
Channel coverage
VHF 2 to 13
UHF 14 to 69
CATV A-8 to A-1, A to W, W+1 to
W+84
Antenna
75-ohm antenna terminal for VHF/
UHF
VCR Inputs and outputs
VIDEO 1 IN
VIDEO 2 INPUT
LINE IN
VIDEO IN, phono jack (1)
Input signal: 1 Vp-p, 75 ohms,
unbalanced, sync negative
AUDIO IN, phono jacks (2)
Input level: 327 mVrms
Input impedance: more than 47
kilohms
MONITOR VIDEO OUT
Phono jack (1)
Output signal: 1 Vp-p, 75 ohm
(unbalanced), sync negative
TV IN
VIDEO IN, phono jack (1)
Input signal: 1 Vp-p, 75 ohms,
unbalanced, sync negative
AUDIO IN, phono jack (2)
Input level: 327 mVrms
Input impedance: more than 47
kilohms
Amplifier
USA model:
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL
HARMONIC DISTORTION
With 8-ohm load, both channels
driven, from 20-20,000 Hz, rated 80
watts per channel minimum RMS
power, with no more than 0.09%
total harmonic distortion from 250
milliwatts to rated output.
Power output
Canadian model:
Stereo mode (8 ohms at 20 Hz - 20
kHz less than 0.09% total harmonic
distortion)
70 W + 70 W
Surround mode
USA model:
(8 ohms at 1 kHz, THD 0.8%)
Front 80 W/ch
Center 80 W
(only in the PRO LOGIC
and THEATER mode)
Rear 80 W
Dynamic power output
8 ohms: 125 W + 125 W
4 ohms: 165 W + 165 W
82 dB (’78 IHF)
(A, 0.5 V)
82 dB (’78 IHF)
(A, 0.5 V)
