8-7
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Not all of the parts for POWER BLOCK
(PSM17-501) are listed.
8-2. ELECTRICAL PARTS LIST
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DS-92 FJ-26 GK-12
* A-6713-652-A DS-92 BOARD, COMPLETE
(ED33MJ/ED66MJ/ED88MJ)
* A-6713-661-A DS-92 BOARD, COMPLETE
(EXCEPT ED33MJ/ED66MJ/ED88MJ)
**********************
(Ref. No. 1,000 Series)
< CONNECTOR >
CN521 1-784-447-11 CONNECTOR, FFC/FPC 5P
< RESISTOR >
R521 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R522 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R523 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R524 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R525 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S521 1-762-196-21 SWITCH, TACT (REW m)
S522 1-762-196-21 SWITCH, TACT (PAUSE X)
S523 1-762-196-21 SWITCH, TACT (FF M)
S524 1-762-196-21 SWITCH, TACT (PLAY H)
S525 1-762-196-21 SWITCH, TACT (STOP x)
S526 1-762-196-21 SWITCH, TACT (EJECT A)
S527 1-762-196-21 SWITCH, TACT (REC z)
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
* A-6713-655-A FJ-26 BOARD, COMPLETE (ED88MJ)
* A-6713-663-A FJ-26 BOARD, COMPLETE
(ED88: ME, SG/ED89/ED95)
* A-6713-667-A FJ-26 BOARD, COMPLETE (EZ66/EZ77)
* A-6713-671-A FJ-26 BOARD, COMPLETE
(ED55/ED66: ME, SG)
* A-6713-677-A FJ-26 BOARD, COMPLETE (ED66MJ)
**********************
(Ref. No. 1,000 Series)
< CONNECTOR >
CN531 1-784-449-11 CONNECTOR, FFC/FPC 7P
< JACK >
CNJ531 1-770-021-11 JACK, PIN 3P (LINE-2 IN)
(ED88/ED89/ED95/EZ66/EZ77)
CNJ531 1-794-162-11 JACK, PIN 3P (LINE-2 IN) (ED55/ED66)
< DIODE >
D531 8-719-071-15 DIODE HZM6.8ZWA1TL
D532 8-719-071-15 DIODE HZM6.8ZWA1TL
D533 8-719-071-15 DIODE HZM6.8ZWA1TL
D534 8-719-017-09 DIODE 02DZ6.2-TPH3
< FILTER >
FL531 1-236-163-11 ENCAPSULATED COMPONENT (EZ66/EZ77)
FL532 1-236-163-11 ENCAPSULATED COMPONENT (EZ66/EZ77)
< JUMPER RESISTOR >
JR541 1-216-296-00 METAL CHIP 0 5% 1/8W
JS531 1-216-296-00 METAL CHIP 0 5% 1/8W
(ED55/ED66/ED88/ED89/ED95)
JS532 1-216-296-00 METAL CHIP 0 5% 1/8W
(ED55/ED66/ED88/ED89/ED95)
JS533 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED55/ED66)
JS534 1-216-295-00 METAL CHIP 0 5% 1/10W
(ED88/ED89/ED95/EZ66/EZ77)
< RESISTOR >
R531 1-216-295-00 METAL CHIP 0 5% 1/10W
(EZ66/EZ77)
R532 1-216-295-00 METAL CHIP 0 5% 1/10W
(EZ66/EZ77)
R533 1-216-021-00 METAL CHIP 68 5% 1/10W
R534 1-216-097-91 RES, CHIP 100K 5% 1/10W
(ED88/ED89/ED95/EZ66/EZ77)
R535 1-216-097-91 RES, CHIP 100K 5% 1/10W
(ED88/ED89/ED95/EZ66/EZ77)
PPPPPPPPPPPPPPPPPPPPPPPPPPPPPP
* A-6791-880-A GK-12 BOARD, COMPLETE (EZ77AS)
**********************
(Ref. No. 2,000 Series)
< CAPACITOR >
C003 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
C006 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C007 1-164-699-11 CERAMIC CHIP 0.0033uF 5.00% 50V
C008 1-164-699-11 CERAMIC CHIP 0.0033uF 5.00% 50V
C009 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C010 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C011 1-107-823-11 CERAMIC CHIP 0.47uF 10.00% 16V
