2-2
2-5. POWER BLOCK REMOVAL 2-7. MA-350 BOARD REMOVAL
2-6. MECHASISM DECK REMOVAL
1 Screw (B3)
(EXCEPT
ED10/EZ10)
2 Three screws
(B3)
3 MA-350
board
3
1 Flat cable
(ED10/EZ10)
5 Connector
(ACE head )
9 Mechanism
deck
4 Connector
(FE head )
3 Connector
(CN101: EXCEPT
ED10/EZ10)
7 Two screws
(BVTP3 × 12)
8 Screw
(BVTP3 × 12)
6 Screw
(B3)
2 Flexible board
(CN201: ED10/EZ10,
CN260: EXCEPT
ED10/EZ10)
Note: When mounting the mechanism deck,
first align ¢ mark on the rotary switch.
2 Power cord
4 Power block
1 Connector
(CN600)
(EXCEPT
ED10/EZ10)
3 Two screws
(B3)
