Sony SRF-M97 - Capacitors; Resistors

16
SRF-M97
SECTION 6
ELECTRICAL PARTS LIST
AMP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1079-165-A AMP BOARD, COMPLETE (JE)
A-1085-528-A AMP BOARD, COMPLETE (EXCEPT AEP, JE)
A-1090-510-A AMP BOARD, COMPLETE (AEP)
*********************
< BATTERY >
BAT302 1-756-305-11 BATTERY, PAS SECONDARY
< CAPACITOR >
C201 1-115-156-11 CERAMIC CHIP 1uF 10V
(AEP, JE)
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT AEP, JE)
C202 1-115-156-11 CERAMIC CHIP 1uF 10V
(AEP, JE)
C202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(EXCEPT AEP, JE)
C203 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP)
C203 1-165-128-11 CERAMIC CHIP 0.22uF 16V
(EXCEPT AEP, JE)
C204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(AEP)
C204 1-165-128-11 CERAMIC CHIP 0.22uF 16V
(EXCEPT AEP, JE)
C205 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(EXCEPT AEP, JE)
C205 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
(AEP)
C206 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(EXCEPT AEP, JE)
C206 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
(AEP)
C207 1-104-847-11 TANTALUM CHIP 22uF 20% 4V
C208 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
C209 1-115-156-11 CERAMIC CHIP 1uF 10V
C210 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C211 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C212 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C213 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C214 1-115-156-11 CERAMIC CHIP 1uF 10V
C215 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C216 1-115-156-11 CERAMIC CHIP 1uF 10V
C217 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C218 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
C219 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C220 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C221 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C222 1-113-619-11 CERAMIC CHIP 0.47uF 10V
C223 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C224 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C302 1-115-156-11 CERAMIC CHIP 1uF 10V
< CONNECTOR >
CN201 1-573-927-11 CONNECTOR, FFC/FPC (ZIF) 18P
< DIODE >
D201 8-719-062-51 DIODE 1PS226-115
D301 8-719-071-34 DIODE RB521S-30-TE61
< IC >
IC201 6-705-694-01 IC TA2179FNG (EL)
< JACK >
J201 1-563-857-31 JACK, HEADPHONE (i)
< SHORT >
JC201 1-216-864-11 SHORT CHIP 0 (JE)
JC202 1-216-864-11 SHORT CHIP 0 (EXCEPT JE)
< COIL >
L201 1-412-983-11 INDUCTOR 2.2uH
L202 1-412-983-11 INDUCTOR 2.2uH
L203 1-412-983-11 INDUCTOR 2.2uH
L301 1-412-935-11 INDUCTOR 0.47uH
< TRANSISTOR >
Q201 6-550-044-01 TRANSISTOR 2SB1689-T106
Q301 6-550-044-01 TRANSISTOR 2SB1689-T106
< RESISTOR >
R201 1-218-965-11 RES-CHIP 10K 5% 1/16W
(JE)
R201 1-218-969-11 RES-CHIP 22K 5% 1/16W
(EXCEPT AEP, JE)
R201 1-218-977-11 RES-CHIP 100K 5% 1/16W
(AEP)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• CAPACITORS
uF: µF
• COILS
uH: µH
When indicating parts by reference
number, please include the board.
• Abbreviation
AUS : Australian model
CH : Chinese model
JE : Tourist model
Ver. 1.1
