7
SRF-M97
Adjustment Location:
CT3
L4
CT1
L1
– MAIN BOARD (Component Side) –
L6
AM VT Voltage Adjustment
FM Tracking
Adjustment
AM Tracking
Adjustment
TP
(VT)
TP
(ANT)
TP
(RF GND)
– MAIN BOARD (Conductor Side) –
