Sony ST-S9 - PANEL Board, SIRCS Board; Tuner Pack (FM;AM)

7
ST-S9
3-5. TUNER PACK (FM/AM)
3-4. PANEL BOARD, SIRCS BOARD
6 SIRCS board
1 two screws
(BVTP2.6
× 8)
1 four screws
(BVTP2.6
× 8)
1 screw
(BVTP2.6
× 8)
(AEP, UK models)
3 PANEL board
4 wire (flat type) (19 core)
(CN602)
2 two claws
5 two claws
3 tuner pack (FM/AM)
2 two screws
(BVTP3 × 8)
1 wire (flat type) (11 core) (except AEP, UK models)
wire (flat type) (15 core) (AEP, UK models)
(CN506)
