8
ST-S9
4
screw
(BVTP3
×
8)
2
five connectors
(CN510, 5031, 5032, 5041, 5042)
1
wire (flat type) (23 core)
(CN508)
1
wire (flat type) (21 core)
(CN509)
6
MAIN board
1
wire (flat type) (19 core)
(CN502)
5
PC board holder
2
connector
(CN601)
3
three screws
(BVTP3
×
8)
4
two screws
(BVTP3
×
8)
1
wire (flat type) (23 core)
(CN603)
4
three screws
(BVTP3
×
8)
3
three screws
(BVTP3
×
8)
6
DSP board
1
wire (flat type) (21 core)
(CN602)
2
connector
(CN601)
5
PC board holde
3-7. DSP BOARD
3-6. MAIN BOARD
