Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
73
STR-DA1ES/DB780
R1710 1-216-809-11 METAL CHIP 100 5% 1/16W
R1711 1-216-809-11 METAL CHIP 100 5% 1/16W
< VIBRATOR >
X1101 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz)
X1201 1-795-297-21 VIBRATOR, CERAMIC (13.6MHz)
X1601 1-781-356-21 VIBRATOR, CERAMIC (16MHz)
**************************************************************
A-4729-155-A DISPLAY BOARD, COMPLETE
************************
* 3-386-245-13 HOLDER (FL)
< CAPACITOR >
C1538 1-164-159-11 CERAMIC 0.1uF 50V
C1575 1-164-159-11 CERAMIC 0.1uF 50V
C1603 1-164-159-11 CERAMIC 0.1uF 50V
C1610 1-164-159-11 CERAMIC 0.1uF 50V
C1611 1-164-159-11 CERAMIC 0.1uF 50V
C1612 1-164-159-11 CERAMIC 0.1uF 50V
C1613 1-164-159-11 CERAMIC 0.1uF 50V
C1614 1-164-159-11 CERAMIC 0.1uF 50V
C1615 1-164-159-11 CERAMIC 0.1uF 50V
C1658 1-164-159-11 CERAMIC 0.1uF 50V
C1659 1-128-813-11 CERAMIC 220PF 5% 50V
C1660 1-128-809-11 CERAMIC 100PF 5% 50V
C1662 1-128-813-11 CERAMIC 220PF 5% 50V
C1666 1-164-159-11 CERAMIC 0.1uF 50V
C1667 1-126-964-11 ELECT 10uF 20% 50V
C1668 1-126-968-11 ELECT 100uF 20% 50V
C1711 1-126-947-11 ELECT 47uF 20% 16V
< CONNECTOR >
CN662 1-784-806-11 HOUSING, CONNECTOR (PC BOARD) 13P
< CONNECTOR >
CNP660 1-770-553-11 CONNECTOR, BOARD TO BOARD 11P
* CNP661 1-568-056-11 PIN, BOARD TO BOARD 8P
CNP662 1-784-807-11 CONNECTOR, BOARD TO BOARD 13P
CNS663 1-784-792-11 CONNECTOR, FFC 31P
< LED >
D1599 8-719-046-39 LED SEL5821A-TP15 (INPUT MODE)
D1601 8-719-075-60 LED SELS5823C-TP15
(DIGITAL CINEMA SOUND)
D1602 8-719-046-39 LED SEL5821A-TP15 (AUTO DEC.)
D1603 8-719-046-39 LED SEL5821A-TP15 (2CH ST)
D1604 8-719-046-39 LED SEL5821A-TP15 (MULTI CH DIRECT)
D1612 8-719-046-39 LED SEL5821A-TP15 (MODE)
< FLUORESCENT INDICATOR TUBE >
FL1601 1-518-718-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC1600 8-759-643-83 IC uPD16315GB-3BS
IC1602 8-759-243-51 IC TC74ACT08P
IC1711 8-759-826-34 IC NJL74H400A
(REMOTE CONTROL RECEIVER)
< TRANSISTOR >
Q1599 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1601 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1602 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1603 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1604 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q1607 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
0 R1601 1-249-381-11 CARBON 1 5% 1/4W F
0 R1602 1-249-381-11 CARBON 1 5% 1/4W F
R1608 1-249-409-11 CARBON 220 5% 1/4W
R1615 1-249-421-11 CARBON 2.2K 5% 1/4W
R1616 1-249-409-11 CARBON 220 5% 1/4W
R1617 1-249-421-11 CARBON 2.2K 5% 1/4W
R1618 1-249-409-11 CARBON 220 5% 1/4W
R1619 1-249-421-11 CARBON 2.2K 5% 1/4W
R1620 1-249-409-11 CARBON 220 5% 1/4W
R1621 1-249-421-11 CARBON 2.2K 5% 1/4W
R1622 1-249-409-11 CARBON 220 5% 1/4W
R1623 1-249-421-11 CARBON 2.2K 5% 1/4W
R1624 1-249-409-11 CARBON 220 5% 1/4W
R1671 1-249-421-11 CARBON 2.2K 5% 1/4W
R1673 1-247-807-31 CARBON 100 5% 1/4W
R1674 1-247-807-31 CARBON 100 5% 1/4W
R1676 1-249-437-11 CARBON 47K 5% 1/4W
R1677 1-249-440-11 CARBON 82K 5% 1/4W
R1711 1-247-807-31 CARBON 100 5% 1/4W
R1712 1-249-393-11 CARBON 10 5% 1/4W
< ROTARY ENCODER >
RV1601 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
**************************************************************
1-685-503-11 H.P BOARD
**********
< CONNECTOR >
CN849 1-784-922-11 PIN, CONNECTOR 5P
< TERMINAL >
* EB849 1-537-738-21 TERMINAL, EARTH
< JACK >
J849 1-815-313-21 JACK (PHONES)
**************************************************************
A-4729-158-A KEY BOARD, COMPLETE
********************
< RESISTOR >
R1902 1-249-413-11 CARBON 470 5% 1/4W
R1903 1-249-417-11 CARBON 1K 5% 1/4W
R1904 1-249-417-11 CARBON 1K 5% 1/4W
DIGITAL DISPLAY H.P KEY
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
