STR-DA3000ES
Items Display Remark
DSP 2 ARAM DSP 2 ARAM The umbers which can be changed will blinks
D
[
*****
]
= XXXXXXXX To select the digit: Press the [TUNING +] or [TUNING --] button
To select the number when the umbers (
*****
or XXXXXXXX)
blinks: Rotate the [--/+] dial
To perform the write when the umbers (XXXXXXXX) blinks:
Press the
[MEMORY/ENTER] button
*****
: coefficient RAM address
XXXXXXXX: coefficient RAM address data
Note: When parenthesis is the position of
coefficient
RAM
address data, up/down of the menu item by
the [MENU] dial
are invalid
Bass management SPECIAL
****
: AUTO or OFF, XX: 02 to 30
BASSMAN. [
****
] XX (switching with [--/+] dial)
DSP boot error SPECIAL Not used for the servicing
DSP BOOT ERROR:XXX
DSP write 1 error SPECIAL Not used for the servicing
DSP WRT1 ERROR:XXX
DSP write 2 error SPECIAL Not used for the servicing
DSP WRT2 ERROR:XXX
DSP write 3 error SPECIAL Not used for the servicing
DSP WRT3 ERROR:XXX
DSP read 1 error SPECIAL Not used for the servicing
DSP RAD1 ERROR:XXX
DSP read 2 error SPECIAL Not used for the servicing
DSP RAD2 ERROR:XXX
DSP read 3 error SPECIAL Not used for the servicing
DSP RAD3 ERROR:XXX
DSP HALT SPECIAL XXX: ON or OFF (switching with
[--/+] dial)
DSP HALT
[
XXX
]
DSP Version display SPECIAL Not used for the servicing
SurV
*
:vXXX
Volume value display SPECIAL Not used for the servicing
(FL/FR) FL
****
FR XXXX
Volume value display SPECIAL Not used for the servicing
(SL/SR) SL
****
SR XXXX
Volume value display SPECIAL Not used for the servicing
(CT/SW) CT
****
SW XXXX
Volume value display SPECIAL Not used for the servicing
(SBL/SBR) SBL
****
SBR XXXX
EEPROM debug SPECIAL
****
: EEPROM address
EEPROM
[
****
]
XX XX: EEPROM data (switching with [--/+] dial)
Super reset SPECIAL Not used for the servicing
SUPER RESET
[
XXX
]
If super reset is performed, “up convert signal level adjustment”
will also be initialized
When EEPROM initialization is required, perform the “all clear
mode” (see page 14 of original service manual)
2nd volume value display SPECIAL XX: 2nd zone volume value (00 to
∞
)
2nd VOLUME –XX (switching with [--/+] dial)
3rd volume value display SPECIAL XX: 3rd zone volume value (00 to
∞
)
3rd VOLUME –XX (switching with [--/+] dial)
FL display duty change SPECIAL XXX: Duty value of FL display (0% to 100%)
DARK OUT DUTY
[
XXX%
]
(switching with [--/+] dial)
SDRAM check SPECIAL Check the operation of LIP SYNC
SDRAM CHECK
[
XXXXX
]
XXXXX: PASS (OK) or ERROR (NG)
Error count display SPECIAL Not used for the servicing
SCOM ERROR COUNT XXX
Version display SPECIAL Not used for the servicing
Sub Micom Ver. X.XX
