Amplifier/Tuner Operation
29
GB
Direct tuning
Enter a frequency of the station directly by
using the remote.
For details on the supplied remote, refer to the
operating instructions supplied with the remote.
STR-DA7ES
Use the supplied remote RM-TP1.
1 Touch RM SELECT.
The RM SELECT screen appears.
2 Touch AMP.
The screen for operiting the receiver
appears.
3 Touch TUNER.
The receiver swiches to the TUNER input.
4 Touch B to return to the RM SELECT
screen.
5 Touch TUNER in the RM SELECT
screen.
6 Touch FM/AM to select the FM or AM
band.
You can also use the FM/AM button on the
receiver.
7 Touch b to display screen 2/3.
8 Touch DIRECT.
9 Touch the numeric buttons to enter the
frequency.
Example 1: FM 102.50 MHz
Touch 1 b 0 b 2 b 5 b 0
Example 2: AM 1350 kHz
(You don’t have to enter the last “0” when
the tuning scale is set to 10 kHz.)
Touch 1 b 3 b 5 b 0
If you’ve tuned in an AM station, adjust the
direction of the AM loop antenna for
optimum reception.
STR-DA4ES
Use the supplied remote RM-LP211.
1 Select “TUNER” from the FUNCTION
list to switch the function to TUNER.
You can also use the FUNCTION control
on the receiver.
2 Select “FM/AM” from the SUB menu to
select the FM or AM band.
You can also use the FM/AM button on the
receiver.
3 Select “DIRECT TUNING” from the SUB
menu.
4 Select the numbers for the frequency
using the NUM menu.
Example 1: FM 102.50 MHz
Press 1 b 0 b 2 b 5 b 0
Example 2: AM 1350 kHz
(You don’t have to enter the last “0” when
the tuning scale is set to 10 kHz.)
Press 1 b 3 b 5 b 0
If you’ve tuned in an AM station, adjust the
direction of the AM loop antenna for
optimum reception.
If you cannot tune in a station and
the entered numbers flash
Make sure you’ve entered the right frequency.
If not, repeat steps 3 and 4. If the entered
numbers still flash, the frequency is not used in
your area.
