Sony STR-DA50ES - Amplifier and Analog Input;Output Specs

49
GB
Additional Information
Specifications
Amplifier section
POWER OUTPUT
Stereo mode (4 ohms at 1 kHz, THD
0.8%)
100 W + 100 W
Surround mode
(4 ohms at 1 kHz, THD
0.8%)
Front: 100 W/ch
Center
a)
: 100W
Rear
a)
: 100 W/ch
a) Depending on the sound field settings and
the source, there may be no sound output.
Harmonic distortion at rated output
Less than 0.05% (with
sound field, tone,
and bass booster
bypassed)
Frequency response
PHONO: RIAA
equalization curve
±0.5 dB
CD, TAPE, MD/DAT,
DVD, TV/LD,
VIDEO 1, 2, and
VIDEO 3:
10 Hz - 50 kHz +0.5/
–2 dB (with sound
field, tone, and bass
booster bypassed)
Inputs (Analog)
PHONO:
Sensitivity: 2.5 mV
Impedance: 50
kilohms
S/N
b)
: 75 dB (A, 2.5
mV
c)
)
CD, DVD:
Sensitivity: 150 mV
Impedance: 50
kilohms
S/N
b)
: 82 dB (A, 150
mV
c)
)
TAPE, MD/DAT, TV/
LD, VIDEO 1, 2, and
VIDEO 3:
Sensitivity: 150 mV
Impedance: 50
kilohms
S/N
b)
: 82 dB (A, 150
mV
c)
)
b) 78’ IHF
c) Weighted network, input level
Inputs (Digital)
DVD (coaxial):
Sensitivity: –
Impedance: 75 ohms
S/N: 100 dB (A, 20
kHz LPF)
CD, DVD, TV/LD,
MD/DAT (Optical):
Sensitivity: –
Impedance: –
S/N: 100 dB (A, 20
kHz LPF)
Outputs (Analog) TAPE, MD/DAT
(REC OUT); VIDEO
1, 2 (AUDIO OUT):
Voltage: 150 mV,
Impedance: 10
kilohms
WOOFER:
Voltage: 2 V
Impedance: 1
kilohms
PHONES:
Accepts low- and
high-impedance
headphones
Outputs (Digital)
MD/DAT (Optical):
Sensitivity: –
Impedance: –
S/N: 100 dB (A, 20
kHz LPF)
BASS BOOST +6 dB at 70 Hz
Sampling Frequency
48 kHz
EQ BASS:
100 Hz~1.0kHz (21
steps)
MID:
500 Hz~5.0kHz (6
steps)
TREBLE:
1.0 kHz~10kHz (21
steps)
Gain levels:
±10 dB, 1 dB step
