Sony STR-DE197 - Page 12

12
STR-DE197
56 RY R1 COIL O Power relay (12V) drive signal output
57 RY POWER O AC power relay (9V) drive signal output
58 RY A O Speaker A relay (12V) drive signal output
59 RY B O Speaker B relay (12V) drive signal output
60 RY HP O Phones relay (12V) drive signal output
61 — — Not used. (Open)
62 to 70 S15 to S7 O Segment drive signal output to the vacuum fluorescent display (FL201).
71 VLOAD — Power supply pin (–24 V)
72 to 77 S6 to S1 O Segment drive signal output to the vacuum fluorescent display (FL201).
78 to 80 DIG10 to DIG8 O Digit drive signal output to the vacuum fluorescent display (FL201).
Pin No. Pin Name I/O Pin Description
